Toyota Camry (JPP)

1988-08 → 1991-06 · chassis SV2#,VZV21 · catalogue 281440 · Europe

Discontinued model Data version 1992-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Console Box & Bracket

22 part groups · 2 illustrations

Illustrations

Figure MBN980 MBN980 1988-08 → — Figure MBN976 MBN976 1988-08 → —

Part groups

PNCDescription
55441D Box, Instrument Panel Coin
55539A Cover, Spare Switch Hole
55620 Holder Assy, Instrument Panel Cup
58804A Panel Sub-assy, Console, Upper
58805B Panel Sub-assy, Console, Lower
58808 Cover Sub-assy, Shifting Hole
58810J Box Assy, Console
58811A Box, Console, Front
58831A Garnish, Console Upper Panel, Front
58833A Cover, Console, Upper
58839A Cover, Console Box Hole
58901A Box Sub-assy, Console, Rear
58902C Bracket Sub-assy, Console Box Mounting
58905 Door Sub-assy, Console Compartment
58907 Hinge Sub-assy, Console Compartment Door
58912 Box, Rear Console, NO.2
58916 Mat, Box Bottom
58919B Plate, Console Box
58959B Cushion, Console Compartment Door
58964 Stopper, Console Compartment Door, NO.1
58965A Stopper, Console Compartment Door, NO.2
58976 Striker, Console Compartment Door Lock
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
