Toyota Lexus ES2##/350/300H
2012-06 → 2018-06 · chassis ASV6#,AVV60,GSV60 · catalogue 282590 · Europe
Supported model
Data version 2018-12
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 44785C — Gasket, Brake Booster | ||||
| 44785-12040 |
Gasket, Brake Booster
2012-06 → 2015-07
ended
|
AVV60 | — | |
| 47210L — Brake Booster Assy, W/Master Cylinder | ||||
| 47050-33090 |
Brake Booster Assy, W/Master Cylinder
2012-06 → 2015-07
ended
|
AVV60 | — | |
| 47220D — Reservoir Assy, Brake Master Cylinder | ||||
| 47220-33120 |
Reservoir Assy, Brake Master Cylinder
2012-06 → 2015-07
ended
|
AVV60 | — | |
| 47220-33300 |
Reservoir Assy, Brake Master Cylinder
2012-06 → 2015-07
ended
|
ASV60,GSV60 | — | |
| 47220-33300 |
Reservoir Assy, Brake Master Cylinder
2015-07 → —
|
ASV6#,GSV60 | — | |
| 47230 — Cap Assy, Brake Master Cylinder Reservoir Filler | ||||
| 47230-20140 |
Cap Assy, Brake Master Cylinder Reservoir Filler
2012-06 → 2015-07
ended
|
AVV60 | — | |
| 47230-33071 |
Cap Assy, Brake Master Cylinder Reservoir Filler
2012-06 → 2014-11
ended
|
ASV60,GSV60 | — | |
| 47230-33072 |
Cap Assy, Brake Master Cylinder Reservoir Filler
2014-11 → 2015-07
ended
|
ASV60,GSV60 | — | |
| 47230-33072 |
Cap Assy, Brake Master Cylinder Reservoir Filler
2015-07 → —
|
ASV6#,GSV60 | — | |
| 47233 — Bracket, Reservoir | ||||
| 47233-33050 |
Bracket, Reservoir
2012-06 → 2015-07
ended
|
AVV60 | — | |
| 47234M — Hose, Reservoir, NO.1 | ||||
| 47234-33060 |
Hose, Reservoir, NO.1
2012-06 → 2015-07
ended
|
AVV60 | — | |
| 47234U — Clip(FOR RESERVOIR HOSE NO.1) | ||||
| 96137-41501 |
Clip(FOR RESERVOIR HOSE NO.1)
2012-06 → 2015-07
ended
|
AVV60 | — | |
| 47235H — Hose, Reservoir, NO.2 | ||||
| 47235-33050 |
Hose, Reservoir, NO.2
2012-06 → 2015-07
ended
|
AVV60 | — | |
| 47235J — Clip(FOR RESERVOIR HOSE NO.2) | ||||
| 96137-41501 |
Clip(FOR RESERVOIR HOSE NO.2)
2012-06 → 2015-07
ended
|
AVV60 | — | |
| 47997A — Label, Accumulator Caution, NO.1 | ||||
| 47997-76010 |
Label, Accumulator Caution, NO.1
2012-06 → 2015-07
ended
|
AVV60 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
