Toyota Mirai
2015-06 → 2020-05 · chassis JPD10 · catalogue 28B510 · Europe
Supported model
Data version 2020-07
Switch & Relay & Computer
100 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 28371E | Relay, Ignition, NO.4 |
| 28371F | Relay, Ignition, NO.5 |
| 69065A | Cylinder Sub-assy, Airbag Cut Off Switch |
| 77037E | Switch Sub-assy, Fuel Filler Opening Lid |
| 82210J | Fusible Link |
| 82600F | Fuse, Fuse Block |
| 82616 | Puller, Fuse |
| 82618 | Fuse, Fuse Block |
| 82620B | Block Assy, Fusible Link |
| 82630D | Holder, Fuse |
| 82641 | Relay, Integration NO.1 |
| 82661 | Cover, Relay Block, NO.1 |
| 82662A | Cover, Relay Block, Upper, NO.1 |
| 82662B | Cover, Relay Block, Upper, NO.2 |
| 82663 | Cover, Relay Block, Lower |
| 82663A | Cover, Relay Block, Lower, NO.2 |
| 82672C | Cover, Junction Block |
| 82673A | Bracket, Junction Block, NO.1 |
| 82673B | Bracket, Junction Block, NO.2 |
| 82715 | Bracket,Wiring Harness Clamp |
| 82730 | Block Assy, Instrument Panel Junction |
| 82741D | Block, Front Compartment Relay |
| 82743A | Block, Front Compartment Relay, NO.3 |
| 82877 | Box, Computer Integration, RH |
| 82878 | Box, Computer Integration, LH |
| 84040 | Master Switch Assy,Multiplex Network |
| 84070 | Computer & Switch Assy, Position Control |
| 84119 | Rheostat, Light Control |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84153 | Switch, Auto High Beam |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84234 | Switch Assy, Courtesy Lamp (FOR REAR DOOR) |
| 84250A | Switch Assy, Steering Pad |
| 84306 | Cable Sub-assy, Spiral |
| 84307 | Cable Sub-assy, Spiral W/Sensor |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84340 | Switch Assy, Stop Lamp |
| 84345 | Adjuster, Stop Lamp Switch Mounting |
| 84550 | Switch Assy, Parking Brake |
| 84650 | Switch Assy, Windshield Wiper |
| 84718 | Switch, Transmission Shift Main |
| 84751 | Switch, Seat Heater |
| 84751F | Switch, Seat Heater |
| 84770A | Switch Assy, Pre-collision System Cancel |
| 84794A | Relay, FR Wiper Deicer |
| 84810 | Switch Assy, Power Window Regulator |
| 84810D | Switch Assy, Power Window Regulator, Rear |
| 84840 | Switch Assy, Luggage Compartment Door Opening |
| 84840C | Switch Assy, Luggage Door Opening, Cancel |
| 84840D | Switch Assy, Luggage Door Opening |
| 84870A | Switch Assy, Outer Mirror |
| 84920 | Switch Assy, Power Seat |
| 84921A | Knob, Power Seat Switch (FOR RECLINING) |
| 84921B | Knob, Power Seat Switch (FOR SLIDE & VERTICAL) |
| 84922 | Switch, Front Power Seat |
| 84927 | Switch, Seat Memory |
| 84973 | Switch, FC Water Release |
| 85530 | Socket Assy, Power Outlet, NO.1 |
| 85535B | Cover, Power Outlet Socket, NO.1 |
| 85912 | Relay, Defogger |
| 85913C | Relay, Heater, NO.1 |
| 85913D | Relay, Heater, NO.2 |
| 85916L | Relay, Rear Fog Lamp |
| 85916P | Relay, Headlamp |
| 85924 | Relay, Ignition Control |
| 85924F | Relay, FC Ignition Control |
| 85925 | Relay, Radiator Fan |
| 85925C | Relay, Radiator Fan, NO.2 |
| 85940 | Relay Assy, Windshield Wiper |
| 85970C | Relay, Fuel Lid Opner |
| 87346L | Relay, Ptc Heater |
| 88150A | Computer Assy, Driving Support |
| 88162 | Sensor, Blind Spot Monitor, RH |
| 88172 | Sensor, Blind Spot Monitor, LH |
| 88790F | Thermistor Assy |
| 89111 | Computer, Network Gateway |
| 89120A | Sensor, Automatic Light Control |
| 89221 | Computer, Multiplex Network Body |
| 89227 | Computer, Multiplex Tilt & Telescopic |
| 89235A | Switch, Tilt & Telescopic |
| 89245B | Sensor, Steering |
| 89422A | Sensor, Water Temperature |
| 89430 | Computer Assy, Outer Mirror Control |
| 89501B | Relay, FC Power, NO.1 |
| 89501C | Relay, FC Power, NO.2 |
| 89530C | Computer Assy, Transmission Control |
| 89531A | Relay, Transmission Control |
| 89611 | Switch, Push Start |
| 89650 | Computer Assy, Power Steering |
| 89669H | Bracket, FC Control Computer, NO.3 |
| 89730A | Relay(FOR SECURITY WARNING) |
| 89747F | Buzzer, Blind Spot Monitor |
| 898A1 | Computer, FC Control |
| 898C0 | Computer Assy, Hydrogen Fuel Control |
| 898D1 | Transmitter, Hydrogen Fuel Control |
| 898D2 | Wire, Hydrogen Fuel Control |
| 89981A | Computer, EV Control |
| 89987D | Bracket, FC Control Computer, NO.1 |
| 89988C | Bracket, FC Control Computer, NO.2 |
| G4131 | Sensor, Hydrogen Tank Pressure |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
