Toyota Mirai

2020-11 → present · chassis JPD20 · catalogue 28B520 · Europe

Supported model Data version 2024-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

20 part groups · 3 illustrations

Illustrations

Figure 745367C 745367C 2020-11 → — Figure 745368A 745368A 2020-11 → — Figure 745369E 745369E 2020-11 → —

Part groups

PNCDescription
16793E Label, Cooling Fan Caution
1A1A7 Label, FC Stack Notice
288A2 Label, Battery Location
74511F Label, Name (IDENTIFICATION LASER LABEL)
74514A Label, Certification Regulation Information
74515C Label, Theft Warning Information
74533B Plate, Shifting Instruction
74571A Film, Label Cover
74571D Film, Label Cover
74751 Label, Tire Pressure Information
77A18 Label, Hydrogen Tank Information, NO.1
77A38 Label, Hydrogen Tank Information, NO.2
77A59 Label, Hydrogen Fueling Caution
77A61 Label, Hydrogen Tank Pressure Information
82685D Plate, Caution
861C8 Label, Mobile Wireless Charger Caution
88723H Label, Cooler Service Caution
88723J Label, Cooler Service Caution, NO.2
89356A Label, Clearance Warning Information
G92A1B Label, EV Coolant System Information
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
