Timing Gear Cover & Rear End Plate

4 part groups · 3 illustrations

Illustrations

Figure 11G942 11G942 2022-07 → — Figure 11G943 11G943 2022-07 → — Figure 11G944 11G944 2022-07 → —

Part groups

PNCDescription
11301C Seal, Oil(FOR TIMING GEAR CASE OR TIMING CHAIN CASE)
11301K Sensor, Crank Position
11321 Case, Timing Gear
16620D Tensioner Assy, V-ribbed Belt
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
