Toyota Supra

2022-07 → present · chassis DB05,06,25,26,45,46,85 · catalogue 291250 · Europe

Supported model Data version 2022-08

Front Bumper & Bumper Stay

39 part groups · 4 illustrations

PNC	Description
52095A	Absorber, Impact
52114A	Bracket, Front Bumper Extension Mounting
52115K	Support, Front Bumper Side
52119A	Cover, Front Bumper
52119K	Repair Kit, Front Bumper
52125	Retainer, Front Bumper, RH
52126	Retainer, Front Bumper, LH
52127C	Cover, Front Bumper Hole
52131A	Reinforcement, Front Bumper
52143J	Bracket, Auxiliary Coolant Radiator, Upper RH
52144L	Bracket, Auxiliary Coolant Radiator, Upper LH
52145J	Bracket, Auxiliary Coolant Radiator, Lower RH
52146J	Bracket, Auxiliary Coolant Radiator, Lower LH
52147J	Reinforcement, Front Bumper, Lower
52148K	Plate, Auxiliary Coolant Radiator Bracket, RH
52149F	Plate, Auxiliary Coolant Radiator Bracket, LH
52521B	Retainer, Front Bumper, Upper
52535	Retainer, Front Bumper Side, RH
52536	Retainer, Front Bumper Side, LH
52537	Retainer, Front Bumper End, RH
52538	Retainer, Front Bumper End, LH
52611	Absorber, Front Bumper Energy
52612A	Support, Front Bumper Energy Absorber
52675	Support, Front Bumper Lower Side, RH
52676	Support, Front Bumper Lower Side, LH
52811A	Duct, Cool Air Intake, NO.1
52821	Duct, Air Intake, RH
52822	Duct, Air Intake, LH
52829B	Grille, Cool Air Intake, RH
52829C	Grille, Cool Air Intake, LH
53111M	Support, Front Bumper, Inner
53112D	Grille, Radiator, Lower RH
53112E	Grille, Radiator, Lower NO.1
53113D	Grille, Radiator, Lower LH
53127D	Grille, Radiator, Lower Side RH
53285P	Duct, Cool Air Intake, LH
53287E	Duct, Cool Air Intake, RH
57208D	Spacer Sub-assy, Front Bumper Support, NO.2
89C48F	Retainer, Ultrasonic Sensor, Front Side

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
