Toyota Cressida

1976-12 → 1980-08 · chassis RX3#,MX3# · catalogue 311230 · Europe

Discontinued model Data version 1981-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Brake Tube & Clamp

21 part groups · 2 illustrations

Illustrations

Figure MC4786E MC4786E 1976-12 → 1980-08 Figure MC4787B MC4787B 1976-12 → 1980-08

Part groups

PNCDescription
47150 Valve Assy, Proportioning
47159 Bracket, Proportioning Valve
47170 Valve Assy, Brake Combination
47181 Plunger, Differential Switch
47181A Spring, Compression(FOR DIFFERENTIAL VALVE SWITCH)
47190 Valve Assy, Proportioning & By-pass
47311 Tube, Front Brake, NO.1
47311A Way(FOR FRONT BRAKE TUBE)
47312 Tube, Front Brake, NO.2
47313 Tube, Front Brake, NO.3
47313A Hose, Flexible, NO.1(FOR FRONT)
47314 Tube, Front Brake, NO.4
47315 Tube, Front Brake, NO.5
47315A Way OR Union(FOR REAR BRAKE TUBE)
47316 Tube, Front Brake, NO.6
47316A Hose, Flexible(FOR REAR BRAKE TUBE)
47318 Tube, Front Brake, NO.8
47318A Way(FOR REAR RH BRAKE TUBE)
47319 Tube, Front Brake, NO.9
47332 Tube, Rear Brake, NO.11
47334 Tube, Rear Brake, NO.13
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
