Toyota Cressida
1984-08 → 1988-08 · chassis YX70,RX7#,GX71,MX7#,LX7# · catalogue 311250 · Europe
Discontinued model
Data version 1989-02
Rear Wiper
11 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 85105R | Protector, Rear Wiper |
| 85120R | Motor And Bracket Assy, Rear Wiper |
| 85160R | Link Assy, Rear Wiper |
| 85168R | Nut, Rear Wiper Link Pivot, NO.1 |
| 85168U | Cover, Rear Wiper |
| 85169R | Washer, Rear Wiper Link Pivot, NO.1 |
| 85178R | Nut (FOR REAR WIPER ARM SETTING) |
| 85190R | Arm Assy, Rear Wiper |
| 85192R | Cover, Rear Wiper Arm |
| 85220R | Blade Assy, Rear Wiper |
| 85221R | Blade, Rear Wiper |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
