Toyota Lexus GS30/35/43/460

2005-01 → 2011-12 · chassis GRS19#,URS190,UZS190 · catalogue 3322A0 · Europe

Supported model Data version 2012-01

Roof Panel & Back Window Glass

37 part groups · 2 illustrations

PNC	Description
04641	Dam Kit, Back Window Glass
56115B	Stopper, Back Window Glass, NO.1
56116D	Stopper, Back Window Glass, NO.2
63102A	Panel Sub-assy, Windshield Header
63106	Reinforcement Sub-assy, Roof Panel, NO.4
63111	Panel, Roof
63118	Support, Roof Panel, RH
63119	Support, Roof Panel, LH
63128	Reinforcement, Roof Panel, NO.6
63141H	Reinforcement, Roof Panel, Center
63142	Reinforcement, Roof Panel, NO.2
63143A	Reinforcement, Roof Panel
63144A	Reinforcement, Roof Panel, NO.4
63146A	Bracket, Roof Panel Reinforcement, NO.1
63148A	Reinforcement, Roof Panel, NO.7
63149E	Bracket, Roof Panel Reinforcement, NO.2
63201G	Glass Sub-assy, Sliding Roof
63203F	Housing Sub-assy, Sliding Roof
63205A	Cable Sub-assy, Sliding Roof Drive
63209	Panel Sub-assy, Roof Wind Deflector
63214F	Channel, Roof Drip, Rear
63217G	Garnish, Sliding Roof Side, RH
63218G	Garnish, Sliding Roof Side, LH
63220A	Hose Assy, Sliding Roof Drain, RH
63236	Clamp, Sliding Roof OR Removable Roof Drain Hose
63240A	Hose Assy, Sliding Roof Drain, LH
63247E	Hose, Sliding Roof Drain, Rear RH
63248E	Hose, Sliding Roof Drain, Rear LH
63251	Weatherstrip, Sliding Roof Panel OR Removable Roof
63260A	Gear Sub-assy, Sliding Roof Drive
63669B	Grommet, Sliding Roof Drain
64101	Panel Sub-assy, Upper Back
64206F	Panel Sub-assy, Room Partition
64227B	Extension, Center Floor TO Blace, NO.1
64228B	Extension, Center Floor TO Brace, NO.2
64811	Glass, Back Window
75571G	Moulding, Back Window, Outside Upper, NO.1

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
