Toyota Lexus GS Series
2012-01 → 2018-09 · chassis ARL10,AWL10,GRL1#,GWL10 · catalogue 3325B0 · Europe
Supported model
Data version 2018-09
Rear Seat & Seat Track
32 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 71075B | Cover, Rear Seat Cushion (FOR BENCH TYPE) |
| 71077B | Cover, Rear Seatback (FOR BENCH TYPE) |
| 71281A | Hinge, Rear Seat Center Armrest |
| 71398A | Holder, Rear Seatback |
| 71452B | Bracket, Rear Seatback |
| 71611 | Pad, Rear Seat Cushion |
| 71651B | Pad, Rear Seatback(FOR BENCH TYPE) |
| 71803B | Board Sub-assy, Rear Seat Armrest Hole |
| 71931A | Support, Rear Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 71960B | Headrest Assy, Rear Seat, Center |
| 72681A | Hook, Rear Seat |
| 72693 | Hook, Rear Seat Cushion Lock |
| 72802A | Hinge Sub-assy, Armrest Console |
| 72803D | Panel Sub-assy, Rear Seat Center Armrest |
| 72805B | Door Sub-assy, Rear Seat Center Armrest |
| 72806B | Holder Sub-assy, Rear Seat Center Armrest Cup |
| 72809 | Lock Sub-assy, Center Armrest |
| 72830 | Armrest Assy, Rear Seat, Center |
| 72830G | Cushion |
| 72831B | Plate, Rear Seat Center Armrest, NO.1 |
| 72839 | Shim, Rear Seat Armrest Hinge |
| 72848A | Cap, Seat Armrest, NO.1 |
| 72860 | Box Assy, Rear Seat Center Armrest |
| 72860A | Box Assy, Rear Seat Center Armrest, NO.2 |
| 72863 | Box, Rear Seat Center Armrest |
| 72888 | Bezel, Rear Seat Center Armrest Box |
| 73705 | Bracket Sub-assy, Child Restraint Seat Anchor, RH |
| 73706 | Bracket Sub-assy, Child Restraint Seat Anchor, LH |
| 73930A | Airbag Assy, Rear Seat, RH |
| 73940A | Airbag Assy, Rear Seat, LH |
| 87501D | Control Sub-assy, Seat Heater |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
