Toyota Lexus LS400
1994-10 → 2000-08 · chassis UCF20 · catalogue 431220 · Europe
Discontinued model
Data version 2001-03
Roof Panel & Back Window Glass
43 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 56116A | Spacer, Windshield Glass |
| 63102A | Panel Sub-assy, Windshield Header |
| 63105D | Frame Sub-assy, Back Window, Upper |
| 63111 | Panel, Roof |
| 63141H | Reinforcement, Roof Panel, Center |
| 63143B | Reinforcement, Roof Panel, NO.3 |
| 63148A | Reinforcement, Roof Panel, NO.7 |
| 63201G | Glass Sub-assy, Sliding Roof |
| 63203F | Housing Sub-assy, Sliding Roof |
| 63209 | Panel Sub-assy, Roof Wind Deflector |
| 63214F | Channel, Roof Drip, Rear |
| 63217G | Garnish, Sliding Roof Side, RH |
| 63218A | Hose(FOR SLIDING ROOF OR REMOVABLE ROOF DRAIN) |
| 63218G | Garnish, Sliding Roof Side, LH |
| 63219A | Garnish, Sliding Roof, Rear |
| 63221 | Casing, Sliding Roof Cable Guide |
| 63223A | Cable, Sliding Roof Drive, RH |
| 63224A | Cable, Sliding Roof Drive, LH |
| 63233C | Panel, Sliding Roof Housing |
| 63235D | Frame, Sliding Roof Housing, Center |
| 63237B | Frame, Sliding Roof Housing, Rear |
| 63239 | Stopper, Sliding Roof Panel |
| 63241B | Bracket, Sliding Roof Housing, NO.1 |
| 63245C | Bracket, Removable Roof, NO.1 |
| 63245F | Bracket, Sliding Rear Mounting |
| 63258E | Joint, Slide Roof Drain Hose, RH |
| 63259E | Strength, Roof Panel, Center NO.9 |
| 63260A | Gear Sub-assy, Sliding Roof Drive |
| 63265B | Gear, Sliding Roof Drive |
| 63603 | Rail Sub-assy, Sliding Roof Drive, RH |
| 63604A | Rail Sub-assy, Sliding Roof Drive, LH |
| 63625 | Block, Sliding Roof Guide, RH |
| 63626 | Block, Sliding Roof Guide, LH |
| 63635A | Garnish, Sliding Roof, Front |
| 63691 | Pad, Roof Silencer, NO.21 |
| 63692 | Pad, Roof Silencer, NO.22 |
| 63693 | Pad, Roof Silencer, NO.23 |
| 63694 | Pad, Roof Silencer, NO.24 |
| 64101 | Panel Sub-assy, Upper Back |
| 64194A | Pad, Back Panel Silencer, Upper |
| 64811 | Glass, Back Window |
| 64818 | Spacer, Back Window Glass |
| 75495 | Clip, Outside Moulding, NO.4 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
