Toyota Lexus LS400
1994-10 → 2000-08 · chassis UCF20 · catalogue 431220 · Europe
Discontinued model
Data version 2001-03
Rear Door Panel & Glass
45 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 65923E | Hook, Curtain |
| 65936B | Rail, Curtain, NO.1 |
| 65937B | Rail, Curtain, NO.2 |
| 65960 | Curtain Assy, Side, Rear RH |
| 65970 | Curtain Assy, Side, Rear LH |
| 65989 | Cap, Curtain Rail |
| 67003 | Panel Sub-assy, Rear Door, RH |
| 67003C | Cushion, Rear Door Panel |
| 67004 | Panel Sub-assy, Rear Door, LH |
| 67113 | Panel, Rear Door, Outer RH |
| 67114 | Panel, Rear Door, Outer LH |
| 67407D | Guide Sub-assy, Rear Door Window, Rear RH |
| 67408D | Guide Sub-assy, Rear Door Window, Rear LH |
| 67435A | Guide, Rear Door Window, Front RH |
| 67436C | Guide, Rear Door Window, Front LH |
| 67488D | Weatherstrip, Rear Door Glass Guide, NO.4 |
| 67489C | Weatherstrip, Rear Door Glass Guide, NO.5 |
| 67603 | Board Sub-assy, Rear Door Trim, RH |
| 67603A | Retainer(FOR REAR DOOR TRIM BOARD) |
| 67604 | Board Sub-assy, Rear Door Trim, LH |
| 67673A | Garnish, Rear Door Frame, RH |
| 67674A | Garnish, Rear Door Frame, LH |
| 67703 | Cover Sub-assy, Rear Door Trim, RH |
| 67704 | Cover Sub-assy, Rear Door Trim, LH |
| 67709 | Grille Sub-assy, Door Speaker, RH |
| 67709A | Grille Sub-assy, Door Speaker, LH |
| 67785D | Cover, Rear Door Trim, Upper RH |
| 67786C | Cover, Rear Door Trim, Upper LH |
| 67841E | Cover, Rear Door Service Hole, RH |
| 67842E | Cover, Rear Door Service Hole, LH |
| 67857B | Protector, Rear Door Panel, RH |
| 67867D | Retainer, Rear Door Weatherstrip, RH |
| 67868D | Retainer, Rear Door Weatherstrip, LH |
| 67871 | Weatherstrip, Rear Door, RH |
| 67872 | Weatherstrip, Rear Door, LH |
| 68103 | Glass Sub-assy, Rear Door, RH |
| 68104 | Glass Sub-assy, Rear Door, LH |
| 68190 | Weatherstrip Assy, Rear Door Glass, Inner |
| 68240A | Weatherstrip Assy, Rear Door Glass, Inner LH |
| 68617A | Pin, Rear Door Check |
| 68618A | Bracket, Rear Door Check Arm, LH |
| 68618D | Bracket, Rear Door Check Arm, RH |
| 68621C | Cover, Rear Door Check, RH |
| 68621E | Cover, Rear Door Check, LH |
| 68630 | Check Assy, Rear Door |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
