Toyota Lexus LS Series

2017-10 → present · chassis GSF50,GVF5#,VXFA55 · catalogue 431560 · Europe

Supported model Data version 2020-11

Hood & Front Fender

39 part groups · 2 illustrations

PNC	Description
53153B	Guide, Front Side Air
53301	Hood Sub-assy
53341B	Insulator, Hood
53341C	Clip(FOR HOOD INSULATOR)
53381	Seal, Hood TO Radiator Support
53381A	Clip(FOR HOOD TO RADIATOR SUPPORT SEAL)
53445A	Cover, Hood Hinge, RH
53446A	Cover, Hood Hinge, LH
53801	Fender Sub-assy, Front RH
53802	Fender Sub-assy, Front LH
53807D	Reinforcement Sub-assy, Front Fender, Top RH
53807F	Clip, Front Fender Reinforcement
53808D	Reinforcement Sub-assy, Front Fender, Top LH
53808F	Clip, Front Fender Reinforcement
53823E	Protector, Front Side Panel, NO.2 RH
53823K	Clip, Front Side Panel Protector
53824B	Protector, Front Side Panel, NO.2 LH
53824G	Clip, Front Side Panel Protector
53827L	Protector, Front Fender Side Panel, RH
53827Q	Clip, Front Fender Side Panel Protector, NO.1
53827R	Clip, Front Fender Side Panel Protector, NO.2
53828K	Protector, Front Fender Side Panel, LH
53828N	Clip, Front Fender Side Panel Protector, NO.1
53828P	Clip, Front Fender Side Panel Protector, NO.2
53833A	Panel, Front Fender Side, Lower RH
53834	Panel, Front Fender Side, Lower LH
53851D	Pad, Front Wheel Opening Extension, RH
53852B	Pad, Front Wheel Opening Extension, LH
53875A	Liner, Front Fender, RH
53875C	Clip, Front Fender Liner
53875P	Screw, NO.1
53875Q	Screw, NO.2
53875S	Grommet, NO.1
53876A	Liner, Front Fender, LH
53879A	Retainer, Front Fender Liner
53879R	Retainer, Front Fender Liner
53879U	Retainer, Front Fender Liner
75871C	Moulding, Front Fender Wheel Opening, RH
75872A	Moulding, Front Fender Wheel Opening, LH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
