Toyota Lexus LS600H/600HL

2012-09 → 2017-08 · chassis UVF4# · catalogue 432220 · Europe

Supported model Data version 2018-03

Roof Panel & Back Window Glass

39 part groups · 2 illustrations

PNC	Description
04641	Dam Kit, Back Window Glass
56115B	Stopper, Back Window Glass, NO.1
56116D	Stopper, Back Window Glass, NO.2
61281B	Bracket, Sliding Roof Housing Side Mounting, NO.1
61282D	Bracket, Sliding Roof Housung Side Mounting, NO.2
63102A	Panel Sub-assy, Windshield Header
63103D	Reinforcement Sub-assy, Roof Panel, NO.3
63111	Panel, Roof
63133B	Frame, Back Window
63138	Bracket, Dome Lamp, NO.2
63142	Reinforcement, Roof Panel, NO.2
63143A	Reinforcement, Roof Panel
63144B	Reinforcement, Roof Panel, NO.4
63148A	Reinforcement, Roof Panel, NO.7
63201G	Glass Sub-assy, Sliding Roof
63203F	Housing Sub-assy, Sliding Roof
63205A	Cable Sub-assy, Sliding Roof Drive
63209	Panel Sub-assy, Roof Wind Deflector
63214F	Channel, Roof Drip, Rear
63217G	Garnish, Sliding Roof Side, RH
63218G	Garnish, Sliding Roof Side, LH
63219C	Plate, Sliding Roof Panel
63220A	Hose Assy, Sliding Roof Drain, RH
63236	Clamp, Sliding Roof OR Removable Roof Drain Hose
63240A	Hose Assy, Sliding Roof Drain, LH
63245D	Bracket, Sliding Roof Housing Rear Mounting, RH
63246D	Bracket, Sliding Roof Housing Rear Mounting, LH
63247E	Hose, Sliding Roof Drain, Rear RH
63248E	Hose, Sliding Roof Drain, Rear LH
63260A	Gear Sub-assy, Sliding Roof Drive
63635A	Garnish, Sliding Roof, Front
63669B	Grommet, Sliding Roof Drain
63692	Pad, Roof Silencer, NO.22
64101	Panel Sub-assy, Upper Back
64185A	Damper, Upper Back, NO.1
64206F	Panel Sub-assy, Room Partition
64227B	Extension, Center Floor TO Blace, NO.1
64228B	Extension, Center Floor TO Brace, NO.2
64811	Glass, Back Window

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
