Toyota Lexus LC500/500H
2023-05 → present · chassis GWZ100,URZ100 · catalogue 433220 · Europe
Supported model
Data version 2023-05
Instrument Panel & Glove Compartment
45 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 55011A | Garnish Sub-assy, Instrument Panel, NO.1 |
| 55012A | Garnish Sub-assy, Instrument Panel, NO.2 |
| 55044B | Panel Sub-assy, Instrument Panel Finish, Upper |
| 55054 | Stopper Sub-assy, Glove Compartment Door |
| 55304D | Panel Sub-assy, Instrument, Main |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55307E | Brace Sub-assy, Instrument Panel, NO.2 |
| 55308B | Brace Sub-assy, Instrument Panel TO Cowl, NO.3 |
| 55309C | Reinforcement Sub-assy, Instrument Panel, Center |
| 55312 | Panel, Instrument, Lower |
| 55328 | Pin, Instrument Panel, NO.1 |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55345A | Clip, Instrument Panel, NO.1 |
| 55346A | Clip, Instrument Panel, NO.2 |
| 55375B | Bracket, Instrument Panel Lower Mounting, NO.2 |
| 55401E | Pad Sub-assy, Instrument Panel Safety |
| 55402D | Pad Sub-assy, Instrument Panel Safety, NO.1 |
| 55403 | Hood Sub-assy, Meter |
| 55408F | Panel Sub-assy, Instrument Panel Speaker, NO.1 |
| 55409F | Panel Sub-assy, Instrument Panel Speaker, NO.2 |
| 55418B | Spacer,Meter Hood |
| 55422C | Panel, Instrument Cluster Finish, Center Upper |
| 55451B | Cover, Instrument Panel Safety Pad |
| 55453C | Cover, Instrument Panel Safety Pad, NO.2 |
| 55458B | Cover, Instrument, Lwr |
| 55458E | Clip(FOR INSTRUMENT LOWER COVER) |
| 55471A | Ornament, Instrument Cluster Finish Panel |
| 55510F | Cover Assy, Speaker Opening, NO.1 |
| 55531A | Panel, Glove Compartment, NO.1 |
| 55532A | Panel, Glove Compartment, NO.2 |
| 55548A | Cover, Instrument Panel Hole |
| 55549B | Cover, Instrument Panel Hole, NO.2 |
| 55550 | Door Assy, Glove Compartment |
| 55557A | Cushion, Glove Compartment Door Check |
| 55569 | Cover, Glove Compartment Door Lock |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55607 | Cover Sub-assy, Instrument Panel Under, NO.2 |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55660 | Register Assy, Instrument Panel, NO.2 |
| 55661A | Bezel, Instrument Panel Register |
| 55670A | Register Assy, Instrument Panel, Center |
| 55981 | Garnish, Defroster Nozzle, NO.1 |
| 73900 | Airbag Assy, Instrument Panel, Lower NO.1 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
| 73990 | Airbag Assy, Instrument Panel, Lower NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
