Toyota Lexus LC500/500H
2023-05 → present · chassis GWZ100,URZ100 · catalogue 433220 · Europe
Supported model
Data version 2023-05
Seat Belt & Child Restraint Seat
23 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 73108 | Base Sub-assy, Front Seat Belt Anchor, RH |
| 73109 | Base Sub-assy, Front Seat Belt Anchor, LH |
| 73119 | Plate, Seat Belt Webbing Clip |
| 73131A | Bracket, Seat Belt |
| 73137A | Cover, Shoulder Belt Anchor, Upr |
| 73172B | Cap, Front Shoulder Belt Hanger, RH |
| 73173D | Cap, Front Shoulder Belt Hanger, LH |
| 73178A | Cap, Seat Belt Anchor Cover |
| 73210 | Belt Assy, Front Seat Outer, RH |
| 73214 | Plate, Front Seat Belt Anchor |
| 73219 | Stopper, Tongue Plate |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73223B | Cover, Front Seat Belt Retractor, RH |
| 73224B | Cover, Front Seat Belt Retractor, LH |
| 73230 | Belt Assy, Front Seat Inner, RH |
| 73233 | Cover, Lap Belt Outer Anchor |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73360C | Belt Assy, Rear NO.1 Seat, Outer RH |
| 73370C | Belt Assy, Rear NO.1 Seat, Outer LH |
| 73390C | Belt Assy, Rear NO.1 Seat, Inner LH |
| 73580B | Belt Assy, Rear Seat, Inner RH |
| 73717 | Cover, Child Restraint Seat Tether Anchor |
| 73719 | Bracket, Child Restraint Seat Tether Anchor |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
