Toyota Lexus Lfa

2010-12 → 2012-12 · chassis LFA10 · catalogue 481210 · Europe

Supported model Data version 2013-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Accelerator Link

6 part groups · 2 illustrations

Illustrations

Figure 781301A 781301A 2010-12 → — Figure 781302A 781302A 2010-12 → —

Part groups

PNCDescription
58517G Pad, Heel
78030 Pedal Assy, Accelerator & Brake
78110K Rod Assy, Accelerator Pedal(W/SENSOR)
78118A Stopper, Accelerator Pedal
78127A Bush, Accelerator Pedal TO Rod
89437H Cover, Sensor
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
