Toyota Lexus Lfa
2010-12 → 2012-12 · chassis LFA10 · catalogue 481210 · Europe
Supported model
Data version 2013-01
Switch & Relay & Computer
77 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 28300 | Relay Assy, Starter |
| 28371 | Relay, Ignition, NO.1 |
| 28371C | Relay, Ignition, NO.2 |
| 28380A | Resister, Fuel Pump |
| 28850 | Sensor Assy, Battery Current |
| 55524J | Cover, Switch Base Hole |
| 69065A | Cylinder Sub-assy, Airbag Cut Off Switch |
| 81980 | Flasher Assy, Turn Signal |
| 82210J | Fusible Link |
| 82600F | Fuse, Fuse Block |
| 82662A | Cover, Relay Block, Upper, NO.1 |
| 82662B | Cover, Relay Block, Upper, NO.2 |
| 82730A | Block Assy, Driver Side Junction |
| 82730D | Block Assy, Passenger Side Junction |
| 83320 | Gage Assy, Fuel Sender |
| 83320B | Gage Assy, Fuel Sender, NO.2 |
| 83520 | Gage Assy,Oil Pressure Sender |
| 84010D | Control & Panel Assy, Integration |
| 84052 | Switch Assy, Un-lock Warning |
| 84091 | Switch Set, Satellite |
| 84091E | Switch Set, Satellite NO.2 |
| 84210 | Switch Assy, Back-up Lamp |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84250A | Switch Assy, Steering Pad |
| 84307 | Cable Sub-assy, Spiral W/Sensor |
| 84310 | Switch Assy, Turn Signal |
| 84390B | Switch Assy, Electric Parking Brake |
| 84450 | Switch Assy, Ignition OR Starter |
| 84480 | Switch Assy, Main |
| 84540 | Switch Assy, Neutral Start |
| 84610F | Switch Assy, Transmission Shift |
| 84810 | Switch Assy, Power Window Regulator |
| 84810J | Switch Assy, Power Window Regulator NO.2 |
| 84840 | Switch Assy, Luggage Compartment Door Opening |
| 84841C | Relay, Fuel Lid Opener |
| 84865 | Switch, Spoiler Control |
| 84870A | Switch Assy, Outer Mirror |
| 84922B | Switch, Front Power Seat, RH |
| 84922C | Switch, Front Power Seat, LH |
| 84970 | Switch Assy, Combination |
| 84970E | Switch Assy, Combination NO.2 |
| 84986 | Switch, Vehicle Stability Control |
| 85530E | Socket Assy, Power Outlet, NO.3 |
| 85535E | Cover, Power Outlet Socket, NO.2 |
| 85912 | Relay, Defogger |
| 85916L | Relay, Rear Fog Lamp |
| 85916N | Relay, Taillamp |
| 85916P | Relay, Headlamp |
| 85926 | Relay, Headlamp Dimmer |
| 85927 | Relay, Cooling Fan |
| 85930G | Relay, Acc |
| 85934A | Relay Condenser Fan |
| 85940 | Relay Assy, Windshield Wiper |
| 85941 | Relay, Windshield Washer |
| 85942 | Relay, Headlamp Cleaner Control |
| 86530 | Relay Assy, Horn |
| 89050 | Computer Assy, Parking Brake |
| 89111 | Computer, Network Gateway |
| 89120A | Sensor, Automatic Light Control |
| 89257B | Computer, Cooling Fan, NO.2 |
| 89465 | Sensor, Oxygen |
| 89467B | Sensor, Air Fuel Ratio |
| 89530C | Computer Assy, Transmission Control |
| 89535 | Relay, Automatic Sequential Gearbox Solenoid |
| 89535A | Relay, Automatic Sequential Gearbox Ignition, NO.2 |
| 89539E | Bracket, Computer |
| 89539Q | Bracket, Computer |
| 89551A | Driver, Sequential Trans Pump Motor |
| 89551B | Relay, Hydraulic Power Unit |
| 895A1 | Relay, Stop Lamp Control |
| 89615 | Sensor, Knock Control |
| 89650 | Computer Assy, Power Steering |
| 89658 | Bracket, Power Steering Computer |
| 89750 | Computer Assy, Spoiler Control |
| F1971 | Cover, Ecu Water Proof |
| G1167 | Controller, Oil Pump Motor |
| G1167A | Relay (FOR OIL PUMP MOTOR) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
