Toyota Lexus RX270/350/450H

2008-12 → 2015-09 · chassis AGL10,GGL15,GYL1# · catalogue 521230 · Europe

Supported model Data version 2016-03
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Hood Lock & Hinge

18 part groups · 2 illustrations

Illustrations

Figure 532929B 532929B 2008-12 → — Figure 532930B 532930B 2008-12 → —

Part groups

PNCDescription
53410 Hinge Assy, Hood, RH
53420 Hinge Assy, Hood, LH
53440A Support Assy, Hood, RH
53450A Support Assy, Hood, LH
53481A Bracket, Hood Support, RH
53482 Bracket, Hood Support, LH
53497 Pad, Hood Hinge, NO.1
53510 Lock Assy, Hood
53510A Spring, Tension(FOR HOOD LOCK)
53550 Hook Assy, Hood Auxiliary Catch
53557 Catch, Hood Auxiliary Hook
53578 Nut, Hood Lock
53579 Cap, Hood Lock Nut
53601 Lever Sub-assy, Hood Lock Control
53614A Clamp, Hood Lock Control Cable, NO.1
53629A Cover, Hood Lock Control Cable
53630 Cable Assy, Hood Lock Control
53630B Clamp(FOR HOOD LOCK CONTROL CABLE)
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
