Rear Seat & Seat Track

92 part groups · 5 illustrations

Illustrations

Part groups

PNC	Description
64928A	Holder, Tonneau Cover Hook
66990	Holder Assy, Cup
71017	Frame Sub-assy, Rear Seatback, RH
71018	Frame Sub-assy, Rear Seatback, LH
71031A	Clip, Center Seat Cushion
71031S	Cover Sub-assy, Center Seat Cushion
71075S	Cover, Rear Seat Cushion, RH (FOR SEPARATE TYPE)
71076S	Cover, Rear Seat Cushion, LH (FOR SEPARATE TYPE)
71077S	Cover, Rear Seatback, RH (FOR SEPARATE TYPE)
71078S	Cover, Rear Seatback, LH(FOR SEPARATE TYPE)
71087	Board Sub-assy, Rear Seatback
71300	Seat Assy, Rear RH
71301S	Frame Sub-assy, Center Seat Cushion
71305S	Frame Sub-assy, Center Seatback
71343C	Hinge, Rear Seatback, Center
71345	Hinge, Rear Seatback
71398H	Cover, Center Seat Hinge, Upper LH
71400	Seat Assy, Rear LH
71499C	Damper, Rear Seat Cushion Spring
71587A	Protector, Rear Seatback Edge
71587C	Protector, Rear Seatback Edge NO.2
71611A	Pad, Rear Seat Cushion, RH
71612A	Pad, Rear Seat Cushion, LH
71614	Pad, Rear Seat Cushion, Center
71650B	Spring Assy, Rear Seat Cushion, RH
71651S	Pad, Rear Seatback, RH(FOR SEPARATE TYPE)
71652S	Pad, Rear Seatback, LH(FOR SEPARATE TYPE)
71660B	Spring Assy, Rear Seat Cushion, LH
71825B	Moulding, Rear Seat Cushion, RH
71826B	Moulding, Rear Seat Cushion, LH
71828B	Moulding, Rear Seat Cushion, Rear RH
71829B	Moulding, Rear Seat Cushion, Rear LH
71835C	Moulding, Rear Seatback, RH
71836C	Moulding, Rear Seatback, LH
71845C	Cap, Rear Seat Cover
71848B	Cap, Seat Adjuster Cover, RH
71849A	Cap, Seat Adjuster Cover, LH
71878A	Cover, Rear Seat Reclining, Inner RH
71879C	Cover, Rear Seat Reclining, Inner LH
71880A	Carpet Assy, Rear Seatback Board, RH
71880B	Clip(FOR REAR SEATBACK CARPET)
71890A	Carpet Assy, Rear Seatback Board, LH
71931A	Support, Rear Seat Headrest
71940A	Headrest Assy, Rear Seat
71956B	Support, Rear Seat Headrest
71960B	Headrest Assy, Rear Seat, Center
72053E	Lever Sub-assy, Reclining Remote Control, RH
72054C	Lever Sub-assy, Reclining Remote Control, LH
72152A	Cover, Rear Seat Track Bracket, Inner
72152B	Cover, Rear Seat Track Bracket, Inner
72159D	Cover, Rear Seat Track Bracket, Outer RH
72159E	Cover, Rear Seat Track Bracket, Outer LH
72525C	Handle, Reclining Adjuster Release, NO.1 RH
72526B	Handle, Reclining Adjuster Release, NO.1 LH
72553A	Protector, Reclining Cover, RH
72554A	Protector, Reclining Cover, LH
72597B	Bezel, Reclining Remote Control Lever, NO.1
72598C	Bezel, Reclining Remote Control, LH
72613B	Striker, Rear Seat Lock
72618	Protector, Rear Seatback Lock Striker
72620B	Cable Assy, Rear NO.1 Seat Lock
72620C	Cable Assy, Rear NO.1 Seat Lock
72630C	Lock Assy, Rear Seatback, RH
72663	Lever, Rear Seat Lock Control, NO.1
72665	Cover, Rear Seatback Lock, RH
72704A	Cable, Rear Seat Reclining Control
72704D	Cable, Rear NO.2 Seat Reclining Control
72749	Spacer, Rear Seat Reclining
72749A	Spacer, Rear Seat Reclining
72749B	Spacer, Rear Seat Reclining, NO.1
72749C	Spacer, Rear Seat Reclining, NO.2
72749D	Spacer, Rear Seat Reclining, NO.3
72805B	Door Sub-assy, Rear Seat Center Armrest
72830	Armrest Assy, Rear Seat, Center
72830G	Cushion
72863	Box, Rear Seat Center Armrest
72881	Support, Rear Seat Center Armrest, RH
72978	Cover, NO.2 Center Seatback
72996	Cover, Rear Seatback, RH
72996A	Cover, Rear Seatback
72997	Cover, Rear Seatback, LH
72997E	Cover, Rear Seat Shield Inner, NO.2
72999B	Cover, Rear Seat Cushion Side, LH
73930A	Airbag Assy, Rear Seat, RH
73940A	Airbag Assy, Rear Seat, LH
74633A	Cap, Coat Hook
78950	Band Assy, Fold Seat Stopper, NO.1
79081C	Cover, Rear Seat, NO.1
79081D	Cover, Rear Seat, NO.2
79081E	Cover, Rear Seat, NO.3
79157	Cover, NO.1 Seatback
79873	Wire, Fold Seatback

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
