Toyota Lexus RX270/350/450H
2008-12 → 2015-09 · chassis AGL10,GGL15,GYL1# · catalogue 521230 · Europe
Supported model
Data version 2016-03
Side Moulding
59 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 62955F | Retainer, Quarter Vent Louver |
| 62955G | Retainer, Quarter Vent Louver |
| 67857L | Protector, Rear Door Panel, RH |
| 67858E | Protector, Rear Door Panel, LH |
| 67865J | Weatherstrip, Front Door, NO.3 RH |
| 67866H | Weatherstrip, Front Door, NO.3 LH |
| 67869G | Clip, Door Weatherstrip |
| 67869M | Clip, Door Weatherstrip |
| 67887F | Weatherstrip, Rear Door, NO.2 RH |
| 67887J | Weatherstrip, Access Panel, NO.2 RH |
| 67887K | Retainer, Access Panel Weatherstrip, NO.2 RH |
| 67888D | Weatherstrip, Rear Door, NO.2 LH |
| 67888J | Weatherstrip, Access Panel, NO.2 LH |
| 67888K | Retainer, Access Panel Weatherstrip, NO.2 LH |
| 67895E | Weatherstrip, Rear Door, NO.3 RH |
| 67896A | Weatherstrip, Rear Door, NO.3 LH |
| 75071A | Moulding Sub-assy, Front Door, Outside RH |
| 75072A | Moulding Sub-assy, Front Door, Outside LH |
| 75075 | Moulding Sub-assy, Rear Door, Outside RH |
| 75076 | Moulding Sub-assy, Rear Door, Outside LH |
| 75551 | Moulding, Roof Drip Side Finish, RH |
| 75552 | Moulding, Roof Drip Side Finish, LH |
| 75553 | Moulding, Roof Drip Side Finish, RH |
| 75553A | Moulding, Roof Drip Side Finish, Rear RH |
| 75554 | Moulding, Roof Drip Side Finish, LH |
| 75554A | Moulding, Roof Drip Side Finish, Rear LH |
| 75555D | Moulding, Roof Drip Side Finish, Center RH |
| 75556C | Moulding, Roof Drip Side Finish, Center LH |
| 75561 | Clip, Roof Drip Side Finish Moulding, NO.1 |
| 75595D | Cover, Roof Drip Side Moulding, Front RH |
| 75596D | Cover, Roof Drip Side Moulding, Front LH |
| 75707 | Moulding Sub-assy, Rear Door Window Frame, RH |
| 75708 | Moulding Sub-assy, Rear Door Window Frame, LH |
| 75710 | Moulding Assy, Front Door Belt, RH |
| 75720 | Moulding Assy, Front Door Belt, LH |
| 75730 | Moulding Assy, Rear Door Belt, RH |
| 75735A | Moulding, Front Door Outside, Lower RH |
| 75736A | Moulding, Front Door Outside, Lower LH |
| 75740 | Moulding Assy, Rear Door Belt, LH |
| 75745 | Moulding, Rear Door Outside, Lower RH |
| 75746 | Moulding, Rear Door Outside, Lower LH |
| 75751C | Moulding, Front Door Window Frame, Front RH |
| 75752C | Moulding, Front Door Window Frame, Front LH |
| 75753 | Moulding, Front Door Window Frame, Upper RH |
| 75754A | Moulding, Front Door Window Frame, Upper LH |
| 75755C | Moulding, Front Door Window Frame, Rear RH |
| 75756C | Moulding, Front Door Window Frame, Rear LH |
| 75763A | Moulding, Rear Door Window Frame, Upper RH |
| 75764A | Moulding, Rear Door Window Frame, Upper LH |
| 75765A | Moulding, Rear Door Window Frame, Rear RH |
| 75766A | Moulding, Rear Door Window Frame, Rear LH |
| 75850A | Moulding Assy, Body Rocker Panel, RH |
| 75860A | Moulding Assy, Body Rocker Panel, LH |
| 75865C | Protector, Rocker Panel Moulding, NO.5 |
| 75866B | Protector, Rocker Panel Moulding, NO.6 |
| 75867A | Clip, Rocker Panel Moulding |
| 75867C | Clip, Rocker Panel Moulding |
| 75873 | Moulding, Quarter Panel Wheel Opening, RH |
| 75874 | Moulding, Quarter Panel Wheel Opening, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
