Toyota Lexus RX450HL/350L
2017-12 → 2022-09 · chassis GGL26,GYL26 · catalogue 522530 · Europe
Supported model
Data version 2023-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 28800 — Battery | ||||
| 28800-31291 note |
Battery
2018-03 → 2019-08
ended
|
2GRFXS GYL26 | — | |
| 28800-38080 note |
Battery
2017-12 → 2019-08
ended
|
2GRFKS GGL26 | — | |
| 28800-31291 note |
Battery
2019-08 → 2023-02
ended
|
2GRFXS GYL26 | — | |
| 28800-38080 note |
Battery
2019-08 → 2023-02
ended
|
2GRFKS GGL26 | — | |
| 28800A — Terminal, Battery Positive | ||||
| 90982-05054 |
Terminal, Battery Positive
2018-03 → 2019-08
ended
|
2GRFXS GYL26 | — | |
| 90982-05056 |
Terminal, Battery Positive
2017-12 → 2019-08
ended
|
2GRFKS GGL26 | — | |
| 90982-05054 |
Terminal, Battery Positive
2019-08 → —
|
2GRFXS GYL26 | — | |
| 90982-05056 |
Terminal, Battery Positive
2019-08 → —
|
2GRFKS GGL26 | — | |
| 28800J — Terminal, Battery Negative | ||||
| 90982-06061 |
Terminal, Battery Negative
2018-03 → 2019-08
ended
|
2GRFXS GYL26 | — | |
| 90982-06070 |
Terminal, Battery Negative
2017-12 → 2019-08
ended
|
2GRFKS GGL26 | — | |
| 90982-06061 |
Terminal, Battery Negative
2019-08 → —
|
2GRFXS GYL26 | — | |
| 90982-06070 |
Terminal, Battery Negative
2019-08 → —
|
2GRFKS GGL26 | — | |
| 28885B — Hose, Battery | ||||
| 28885-31060 |
Hose, Battery
2018-03 → 2019-08
ended
|
2GRFXS GYL26 | — | |
| 28885-31060 |
Hose, Battery
2019-08 → —
|
2GRFXS GYL26 | — | |
| 28899 — Insulator, Battery | ||||
| 28899-31100 |
Insulator, Battery
2018-03 → 2019-08
ended
|
2GRFXS GYL26 | — | |
| 28899-31220 |
Insulator, Battery
2017-12 → 2019-08
ended
|
2GRFKS GGL26 | — | |
| 28899-31100 |
Insulator, Battery
2019-08 → 2021-09
ended
|
2GRFXS GYL26 | — | |
| 28899-31220 |
Insulator, Battery
2019-08 → —
|
2GRFKS GGL26 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
