Toyota Lexus RX450HL/350L

2017-12 → 2022-09 · chassis GGL26,GYL26 · catalogue 522530 · Europe

Supported model Data version 2023-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Hood Lock & Hinge

19 part groups · 2 illustrations

Illustrations

Figure 535488A 535488A 2017-12 → — Figure 535489A 535489A 2018-03 → —

Part groups

PNCDescription
53336 Bracket, Hood Stay, RH
53337C Bracket, Hood Stay, LH
53410 Hinge Assy, Hood, RH
53420 Hinge Assy, Hood, LH
53440A Support Assy, Hood, RH
53450A Support Assy, Hood, LH
53481A Bracket, Hood Support, RH
53482 Bracket, Hood Support, LH
53510 Lock Assy, Hood
53510A Spring, Tension(FOR HOOD LOCK)
53510D Spring, Tension(FOR HOOD LOCK)
53510E Spring, Tension(FOR HOOD LOCK)
53525 Protector, Hood Lock Release Lever
53601 Lever Sub-assy, Hood Lock Control
53614 Clamp, Hood Lock Control Cable
53629A Cover, Hood Lock Control Cable
53630 Cable Assy, Hood Lock Control
53630B Clamp(FOR HOOD LOCK CONTROL CABLE)
53639 Cover, Hood Lock Control Cable, NO.2
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
