Toyota Highlander/Kluger
2013-12 → 2019-11 · chassis ASU50,GSU5# · catalogue 526220 · Europe
Supported model
Data version 2019-11
Rear Seat & Seat Track
129 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 71015 | Frame Sub-assy, Rear Seat Cushion |
| 71016A | Frame Sub-assy, Rear Seat Cushion, LH |
| 71017 | Frame Sub-assy, Rear Seatback, RH |
| 71018 | Frame Sub-assy, Rear Seatback, LH |
| 71075S | Cover, Rear Seat Cushion, RH (FOR SEPARATE TYPE) |
| 71076S | Cover, Rear Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71077S | Cover, Rear Seatback, RH (FOR SEPARATE TYPE) |
| 71078S | Cover, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71485 | Cover, Rear Seat Hinge |
| 71485B | Cover, Rear Seat Hinge |
| 71486C | Cover, Rear Seat Hinge, LH |
| 71611A | Pad, Rear Seat Cushion, RH |
| 71612A | Pad, Rear Seat Cushion, LH |
| 71628E | Spacer, Rear Seat Cushion |
| 71629 | Cover, Rear Seat Cushion Hinge |
| 71639 | Cover, Rear Seat Cushion Hinge, LH |
| 71651S | Pad, Rear Seatback, RH(FOR SEPARATE TYPE) |
| 71652S | Pad, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71691E | Cover, Rear Seat Cushion Hinge, NO.1 |
| 71692E | Cover, Rear Seat Cushion Hinge, NO.2 |
| 71693A | Cover, Rear Seat Cushion Hinge, NO.3 |
| 71694 | Cover, Rear Seat Cushion Hinge, Lower LH |
| 71704 | Band Sub-assy, Rear Side Seat |
| 71704B | Band Sub-assy, Rear Side Seat, NO.2 |
| 71778C | Moulding, Rear Seatback |
| 71825B | Moulding, Rear Seat Cushion, RH |
| 71826B | Moulding, Rear Seat Cushion, LH |
| 71828B | Moulding, Rear Seat Cushion, Rear RH |
| 71829B | Moulding, Rear Seat Cushion, Rear LH |
| 71833A | Cover, Rear Seat Reclining, NO.1 RH |
| 71834A | Cover, Rear Seat Reclining, NO.1 LH |
| 71843A | Cover, Rear Seat Reclining, NO.2 RH |
| 71844A | Cover, Rear Seat Reclining, NO.2 LH |
| 71845D | Cap, Rear Seat Cover, RH |
| 71846E | Cap, Rear Seat Cover, LH |
| 71848K | Cap, Seat Adjuster Cover |
| 71865 | Bezel, Rear Seat Cover, NO.1 |
| 71866A | Bezel, Rear Seat Cover, NO.2 |
| 71866B | Bezel, Rear Seat Cover, NO.2 |
| 71880A | Carpet Assy, Rear Seatback Board, RH |
| 71890A | Carpet Assy, Rear Seatback Board, LH |
| 71931B | Support Assy, Rear NO.1 Seat Headrest |
| 71931C | Support Assy, Rear NO.2 Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 71940E | Headrest Assy, NO.2 Seat |
| 71960B | Headrest Assy, Rear Seat, Center |
| 72057 | Lever Sub-assy, Rear Seat Lock Control, RH |
| 72058A | Lever Sub-assy, Rear Seat Lock Control, LH |
| 72084 | Pad Sub-assy, Rear Seat Center Armrest, NO.2 |
| 72087 | Cover, Rear Seat Center Armrest, NO.1 |
| 72123C | Cover, Seat Track Bracket, Outer Front RH |
| 72124C | Cover, Seat Track Bracket, Outer Front LH |
| 72127G | Cover, Seat Track Bracket, Inner Front RH |
| 72128G | Cover, Seat Track Bracket, Inner Front LH |
| 72137S | Cover, Seat Track Bracket, Outer Rear RH |
| 72138M | Cover, Seat Track Bracket, Outer Rear LH |
| 72157B | Cover, Rear Seat Track Bracket, Inner RH |
| 72158B | Cover, Seat Track Bracket, Inner LH |
| 72160 | Track Assy, Rear Seat, Outer RH |
| 72170 | Track Assy, Rear Seat, Outer LH |
| 72180C | Track Assy, Rear Seat, Inner RH |
| 72190 | Track Assy, Rear Seat Inner, LH |
| 72210G | Cable Assy, Rear NO.1 Seat Track Control, RH |
| 72210H | Cable Assy, Rear NO.1 Seat Track Control, LH |
| 72265A | Cover, Seat Track Upper Rail, RH |
| 72266A | Cover, Seat Track Upper Rail, LH |
| 72307 | Link Sub-assy, Reclining Control, RH |
| 72308 | Link Sub-assy, Reclining Control, LH |
| 72525C | Handle, Reclining Adjuster Release, NO.1 RH |
| 72526E | Handle, Reclining Adjuster Release, LH |
| 72551A | Cover, Reclining Hinge |
| 72552E | Cover, Reclining Hinge, LH |
| 72591 | Knob, Reclining Remote Control Lever |
| 72593C | Knob, Reclining Remote Control Lever, NO.2 |
| 72615A | Cover, Rear Seatback Lock Striker, RH |
| 72615B | Cover, Rear Seat Lock Striker, RH |
| 72615H | Cover, Rear Seatback Lock Striker, NO.1 |
| 72616A | Cover, Rear Seatback Lock Striker, LH |
| 72616B | Cover, Rear Seat Lock Striker |
| 72622C | Bush, Rear Seatback Protector Shaft |
| 72649 | Spring, Rear Seat Cushion Support |
| 72660J | Cable Assy, Rear NO.2 Seat Cushion Lock |
| 72660K | Cable Assy, Rear NO.2 Seat Cushion Lock, RH |
| 72660L | Cable Assy, Rear NO.2 Seat Cushion Lock, LH |
| 72704A | Cable, Rear Seat Reclining Control |
| 72704B | Cable, Rear Seat Reclining Control, NO.2 |
| 72704F | Cable, Rear Seat Reclining Control, NO.3 |
| 72704G | Cable, Rear Seat Reclining Control, NO.4 |
| 72806D | Holder Sub-assy, Rear Seat Center Armrest Cup |
| 72830 | Armrest Assy, Rear Seat, Center |
| 72831B | Plate, Rear Seat Center Armrest, NO.1 |
| 72831C | Plate, Rear Seat Center Armrest, NO.2 |
| 72868 | Cover, Center Armrest Hinge, RH |
| 72996 | Cover, Rear Seatback, RH |
| 72996A | Cover, Rear Seatback |
| 72996E | Cover, Rear Seat Shield Inner, NO.1 |
| 72997 | Cover, Rear Seatback, LH |
| 73315A | Cover, RR Seat Belt, Inner RH |
| 73316A | Cover, RR Seat Belt, Inner LH |
| 79021 | Cover Sub-assy, NO.2 Seat Cushion, RH |
| 79022 | Cover Sub-assy, NO.2 Seat Cushion, LH |
| 79023 | Cover Sub-assy, NO.2 Seatback, RH |
| 79024 | Cover Sub-assy, NO.2 Seatback, LH |
| 79030B | Leg Assy, Rear NO.2 Seat, RH |
| 79101 | Frame Sub-assy, NO.1 Seat Cushion |
| 79102 | Frame Sub-assy, NO.1 Seat Cushion, LH |
| 79201B | Frame Sub-assy, NO.2 Seat Cushion, RH |
| 79202 | Frame Sub-assy, NO.2 Seat Cushion, LH |
| 79203A | Frame Sub-assy, NO.2 Seatback, RH |
| 79204A | Frame Sub-assy, NO.2 Seatback, LH |
| 79207B | Board Sub-assy, NO.2 Seatback, RH |
| 79209B | Board Sub-assy, NO.2 Seatback, LH |
| 79220B | Clip, NO.2 Seat Cushion |
| 79235D | Pad, NO.2 Seat Cushion, RH |
| 79245C | Pad, NO.2 Seat Cushion, LH |
| 79273 | Cover, NO.2 Seat Hinge |
| 79273A | Cover, NO.2 Seat Hinge, NO.2 |
| 79273B | Cover, NO.2 Seat Hinge, NO.3 |
| 79273C | Cover, NO.2 Seat Hinge, NO.4 |
| 79275C | Pad, NO.2 Seatback, RH |
| 79285 | Pad, NO.2 Seatback, LH |
| 79956A | Clip (FOR REAR SEAT LEG BRACKET COVER) |
| 79959 | Cover, RR Seat Leg |
| 79959C | Cover, Rear Seat Leg |
| 87501D | Control Sub-assy, Seat Heater |
| 87510P | Heater Assy, Seat |
| 87510Q | Heater Assy, Seat |
| 87510R | Heater Assy, Seat |
| 87510S | Heater Assy, Seat |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
