Toyota C-hr

2016-10 → present · chassis MAXH10,NGX10,50,ZGX10,ZYX1# · catalogue 528510 · Europe

Supported model Data version 2019-09

Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Rear Fog Lamp

5 part groups · 2 illustrations

Illustrations

Figure 817940A

817940A 2016-10 → —

Figure 819159A

819159A 2019-09 → —

Part groups

PNC	Description
81210C	Bulb, Rear Fog Lamp
81215H	Socket, Rear Fog Lamp
81455B	Led, Rear Fog Lamp
81457C	Lens & Body, Rear Fog Lamp
81480B	Lamp Assy, Rear Fog

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
