Toyota Lexus UX300E

2020-04 → 2022-11 · chassis KMA10 · catalogue 538210 · Europe

Supported model Data version 2023-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

17 part groups · 3 illustrations

Illustrations

Figure 745173A 745173A 2020-04 → — Figure 745174D 745174D 2020-04 → — Figure 745175B 745175B 2020-04 → —

Part groups

PNCDescription
11285A Label, Coolant System Notice
16793E Label, Cooling Fan Caution
47997C Label, Accumulator Caution, NO.1
69339C Label, Child Protector Information
74511F Label, Name (IDENTIFICATION LASER LABEL)
74515C Label, Theft Warning Information
74528J Label, Power Back Door Caution
74533B Plate, Shifting Instruction
74541B Plate, Compact Spare Tire Caution
74541E Plate, Compact Spare Tire Caution
74573D Label, Electric Vehicle Battery Caution
74573E Label, Electric Vehicle Battery Caution, NO.2
74751 Label, Tire Pressure Information
88723J Label, Cooler Service Caution, NO.2
89356A Label, Clearance Warning Information
G9275 Label, Battery Caution, NO.1
G92A1 Label, Hybrid Coolant System Information
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
