Toyota Lexus Lbx

2023-11 → present · chassis MAYH1# · catalogue 543210 · Europe

Supported model Data version 2023-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Deck Board & Deck Trim Cover

14 part groups · 2 illustrations

Illustrations

Figure 6458A7C 6458A7C 2023-12 → — Figure 6458A8C 6458A8C 2023-12 → —

Part groups

PNCDescription
58387B Plate, Rear Floor Finish
58460D Striker Assy, Luggage Hold Belt
58460J Striker Assy, Luggage Hold Belt
58731C Cap, Rear Absorber
58732C Cap, Rear Absorber
64718A Cover, Deck Trim Service Hole
64730B Panel Assy, Deck Trim Side, RH
64740C Panel Assy, Deck Trim Side, LH
64741B Box, Deck Side Trim, RH
64742C Box, Deck Side Trim, LH
64771G Cover, Spare Wheel
64910J Cover Assy, Tonneau
64993 Box, Deck Floor, Rear
66311 Hook, Rope
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
