Toyota Liteace Van,Wagon
1985-10 → 1988-08 · chassis KM3#,CM35 · catalogue 631530 · Europe
Discontinued model
Data version 1988-12
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 17303B — Pipe Sub-assy, Air, NO.1 | ||||
| 17303-13140 note |
Pipe Sub-assy, Air, NO.1
1985-10 → 1988-08
ended
|
5K KM36 5F;5K KM30 +1 | — | |
| 23262 — Valve, Bimetal Vacuum Switching, NO.1 | ||||
| 90925-05051 |
Valve, Bimetal Vacuum Switching, NO.1
1985-10 → 1988-08
ended
|
5K KM30,36 02S,08S | — | |
| 90925-05051 note |
Valve, Bimetal Vacuum Switching, NO.1
1985-10 → 1988-08
ended
|
5K KM36 4F 05S | — | |
| 90925-05063 |
Valve, Bimetal Vacuum Switching, NO.1
1985-10 → 1986-08
ended
|
5K KM31,36 05S | — | |
| 90925-05063 |
Valve, Bimetal Vacuum Switching, NO.1
1986-08 → 1988-08
ended
|
5K KM36 05S | — | |
| 23265 — Filter, Gas, NO.1 | ||||
| 90917-11023 note |
Filter, Gas, NO.1
1985-10 → 1986-08
ended
|
5K KM36 5F;5K KM30 +1 | — | |
| 90917-11024 note |
Filter, Gas, NO.1
1986-08 → 1988-08
ended
|
5K KM30 DLX | — | |
| 90917-11024 note |
Filter, Gas, NO.1
1986-08 → 1988-08
ended
|
5K KM36 5F | — | |
| 23281 — Valve, Vacuum Transmitting, NO.1 | ||||
| 90925-01014 |
Valve, Vacuum Transmitting, NO.1
1985-10 → 1988-08
ended
|
5K KM3# | — | |
| 23288 — Jet, NO.1 | ||||
| 90925-04006 note |
Jet, NO.1
1985-10 → 1988-08
ended
|
5K KM3# | — | |
| 23289 — Jet, NO.2 | ||||
| 90925-04005 note |
Jet, NO.2
1985-10 → 1988-08
ended
|
5K KM36 5F;5K KM30 +1 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
