Toyota Liteace Van,Wagon
1985-10 → 1988-08 · chassis KM3#,CM35 · catalogue 631530 · Europe
Discontinued model
Data version 1988-12
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82690 — Resistor Assy, Dim Dip Lamp | ||||
| 82690-95700 note |
Resistor Assy, Dim Dip Lamp
1986-11 → 1987-08
ended
|
KM36 RHD | — | |
| 82690-95700 note |
Resistor Assy, Dim Dip Lamp
1987-08 → 1988-08
ended
|
CM35,KM36 RHD | — | |
| 83320 — Gage Assy, Fuel Sender | ||||
| 83320-80043 |
Gage Assy, Fuel Sender
1985-10 → 1986-08
ended
|
CM35,KM3# | — | |
| 83320-80043 note |
Gage Assy, Fuel Sender
1986-08 → 1988-08
ended
|
KM30 DLX;KM36 LHD MRF +1 | — | |
| 83320-80064 |
Gage Assy, Fuel Sender
1986-08 → 1988-08
ended
|
KM3# | — | |
| 83320-80065 |
Gage Assy, Fuel Sender
1986-08 → 1988-08
ended
|
CM35 | — | |
| 83361 — Gasket, Fuel Sender Gage | ||||
| 83361-20030 |
Gasket, Fuel Sender Gage
1985-10 → 1988-08
ended
|
CM35,KM3# | — | |
| 84340 — Switch Assy, Stop Lamp | ||||
| 84340-22072 |
Switch Assy, Stop Lamp
1985-10 → 1988-08
ended
|
CM35,KM3# | — | |
| 84550 — Switch Assy, Parking Brake | ||||
| 84380-35010 |
Switch Assy, Parking Brake
1985-10 → 1988-08
ended
|
CM35,KM3# LHD | — | |
| 84550-12060 |
Switch Assy, Parking Brake
1985-10 → 1988-08
ended
|
CM35,KM36 RHD | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
