Toyota Liteace Van,Wagon

1985-10 → 1988-08 · chassis KM3#,CM35 · catalogue 631530 · Europe

Discontinued model Data version 1988-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Roof Headlining & Silencer Pad

18 part groups · 2 illustrations

Illustrations

Figure MBK028A MBK028A 1985-10 → — Figure MBJ884A MBJ884A 1985-10 → —

Part groups

PNCDescription
63310 Headlining Assy, Roof
63311A Headlining, Roof NO.1
63312A Headlining, Roof, NO.2
63313A Headlining, Roof, NO.3
63341 Pad, Roof Silencer, NO.1
63342 Pad, Roof Silencer, NO.2
63343 Pad, Roof Silencer, NO.3
63361 Support, Roof Headlining, NO.1
63362 Support, Roof Headlining, NO.2
63363 Support, Roof Headlining, NO.3
63364 Support, Roof Headlining, NO.4
63365 Support, Roof Headlining, NO.5
63366 Support, Roof Headlining, NO.6
63372C Hook, Roof Headlining Support
63375 Moulding, Roof Vinyl
63375A Moulding, Roof Vinyl, NO.2
63379B Cover, Roof Headlining Moulding End
63381 Retainer, Headlining, Front
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
