Toyota Liteace Van,Wagon
1985-10 → 1988-08 · chassis KM3#,CM35 · catalogue 631530 · Europe
Discontinued model
Data version 1988-12
Seat & Seat Track
114 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 58936A | Band, Engine Service Hole Cover Support |
| 71011S | Frame Sub-assy, Front Seat Cushion, RH |
| 71012S | Frame Sub-assy, Front Seat Cushion, LH |
| 71071S | Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71072S | Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71073S | Cover, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71074S | Cover, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71257 | Plate, Rear Seatback Anchor |
| 71274 | Knob, Front Seat Hinge |
| 71280A | Hinge Assy, Front Seatback, LH |
| 71324A | Cushion, Rear Seat |
| 71410S | Cushion Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71420S | Cushion Assy, Front Seat, LH (FOR SEPARATE TYPE) |
| 71430S | Back Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71440S | Back Assy, Front Seat, LH(FOR SEPARATE TYPE) |
| 71511S | Pad, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71512S | Pad, Front Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71551S | Pad, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71552S | Pad, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71587 | Protector, Front Seatback Edge |
| 71588 | Protector, Front Seatback Edge, NO.2 |
| 71691B | Cover, Rear Seat Lock, Outer RH |
| 71691C | Cover, Rear Seat Lock, Inner RH |
| 71692B | Cover, Rear Seat Lock, Outer LH |
| 71692C | Cover, Rear Seat Lock, Inner LH |
| 71707 | Hinge Sub-assy, Rear Seat Side |
| 71777 | Cover, Rear Seat Side Hinge Female |
| 71778 | Cover, Rear Seat Side Hinge Male, RH |
| 71779 | Cover, Rear Seat Side Hinge Male, LH |
| 71811C | Cover, Reclining Adjuster, RH |
| 71812 | Clip (FOR FRONT SEAT CUSHION COVER) |
| 71812C | Cover, Reclining Adjuster, LH |
| 71831D | Cover, Front Seat Hinge, RH |
| 71832D | Cover, Front Seat Hinge, LH |
| 71833A | Cover, Rear Seat Reclining, NO.1 RH |
| 71834A | Cover, Rear Seat Reclining, NO.1 LH |
| 71835D | Cover, Rear Seat Reclining, Lower RH |
| 71836D | Cover, Rear Seat Reclining, Lower LH |
| 71837D | Cover, Rear Seat Reclining, Inner RH |
| 71838D | Cover, Rear Seat Reclining, Inner LH |
| 71843A | Cover, Rear Seat Reclining, NO.2 RH |
| 71844A | Cover, Rear Seat Reclining, NO.2 LH |
| 71950 | Headrest Assy, Front Seat |
| 71956A | Support, Front Seat Headrest |
| 72065 | Belt Sub-assy, Rear Seat Hook, RH |
| 72066 | Belt Sub-assy, Rear Seat Hook, LH |
| 72160 | Track Assy, Rear Seat, Outer RH |
| 72170 | Track Assy, Rear Seat, Outer LH |
| 72180 | Track Assy, Rear Seat, Inner RH |
| 72190 | Track Assy, Rear Seat Inner, LH |
| 72301 | Wire Sub-assy, Seat Track Equalizing |
| 72302B | Wire Sub-assy, Rear Seat Track Equalizing |
| 72312 | Wire, Rear Seat Track Equalizing |
| 72510 | Adjuster Assy, Reclining Seatback, RH |
| 72520 | Adjuster Assy, Reclining Seatback, LH |
| 72524 | Handle, Reclining Adjuster Release |
| 72613A | Striker, Front Seat Lock |
| 72630A | Lock Assy, Rear NO.1 Seat |
| 72650B | Lock Assy, Rear NO.3 Seat, RH |
| 72651A | Cover, Rear Seat Lock |
| 72658 | Knob, Rear Seat Handle |
| 72660B | Lock Assy, Rear NO.3 Seat, LH |
| 72665 | Cover, Rear Seatback Lock, RH |
| 72666 | Cover, Rear Seatback Lock, LH |
| 72670B | Lock Assy, Rear Seat Cushion, RH |
| 72680B | Lock Assy, Rear Seat Cushion, LH |
| 72695A | Cable, Rear Seat Lock Control |
| 72710C | Adjuster Assy, NO.1 Seat Reclining, RH |
| 72720C | Adjuster Assy, NO.1 Seat Reclining, LH |
| 72730C | Adjuster Assy, NO.2 Seat Reclining, RH |
| 72740C | Adjuster Assy, NO.2 Seat Reclining, LH |
| 72750C | Adjuster Assy, NO.3 Seat Reclining, RH |
| 72760C | Adjuster Assy, NO.3 Seat Reclining, LH |
| 72830 | Armrest Assy, Rear Seat, Center |
| 79011A | Cover Sub-assy, NO.1 Seat Cushion |
| 79013A | Cover Sub-assy, NO.1 Seatback |
| 79021A | Cover Sub-assy, NO.2 Seat Cushion |
| 79023A | Cover Sub-assy, NO.2 Seatback |
| 79031A | Cover Sub-assy, NO.3 Seat Cushion |
| 79033A | Cover Sub-assy, NO.3 Seatback |
| 79120A | Cushion Assy, NO.1 Seat |
| 79135 | Pad, NO.1 Seat Cushion |
| 79137 | Cover, NO.1 Seat Hinge |
| 79139 | Cover, Rear Seat Leg |
| 79140A | Back Assy, NO.1 Seat |
| 79160 | Spring Assy, NO.1 Seat Cushion |
| 79169 | Rod, Rear Seat Hinge Connector |
| 79175 | Pad, NO.1 Seatback |
| 79180 | Spring Assy, NO.1 Seatback |
| 79220A | Cushion Assy, NO.2 Seat |
| 79232 | Leg, Rear NO.2 Seat, RH |
| 79235 | Pad, NO.2 Seat Cushion |
| 79236A | Cover, NO.2 Seat Leg |
| 79240A | Back Assy, NO.2 Seat |
| 79242 | Leg, Rear NO.2 Seat, LH |
| 79246 | Cover, NO.2 Seat Leg, NO.1 |
| 79246A | Cover, NO.2 Seat Leg, NO.2 |
| 79257 | Board, NO.2 Seat |
| 79260 | Spring Assy, NO.2 Seat Cushion |
| 79275 | Pad, NO.2 Seatback |
| 79320A | Cushion Assy, NO.3 Seat |
| 79335 | Pad, NO.3 Seat Cushion |
| 79340A | Back Assy, NO.3 Seat |
| 79354 | Cover, NO.3 Seatback Hinge |
| 79361 | Bracket, NO.3 Seat Support |
| 79372 | Cover, NO.3 Seat Front Bracket, RH |
| 79374 | Cover, NO.3 Seat Leg, Rear RH |
| 79375 | Pad, NO.3 Seatback |
| 79378 | Cover, NO.3 Seat Cushion Hinge |
| 79382 | Cover, NO.3 Seat Front Bracket, LH |
| 79383 | Cover, NO.3 Seat Bracket Support |
| 79384 | Cover, NO.3 Seat Leg, Rear LH |
| 79621 | Stopper, NO.2 Seat Cushion |
| 79946 | Stay, Seat Leg, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
