Toyota Liteace Van,Wagon
1988-08 → 1992-01 · chassis KM3#,CM3# · catalogue 631540 · Europe
Discontinued model
Data version 1992-09
Shift Lever & Retainer
19 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 33503F | Lever Sub-assy, Shift(FOR FLOOR SHIFT) |
| 33504F | Knob Sub-assy, Shift Lever |
| 33506F | Retainer Sub-assy, Control Shift Lever (FOR FLOOR SHIFT) |
| 33506Q | Grommet, NO.1(FOR CONTROL SHIFT LEVER RETAINER) |
| 33506S | Collar, NO.1(FOR CONTROL SHIFT LEVER RETAINER) |
| 33539 | Cushion, Shift Lever Anti-rattle |
| 33548F | Bush, NO.1, Shift Lever (FOR FLOOR SHIFT) |
| 33554 | Cap, Shift Lever |
| 33556B | Bush (FOR TRANSMISSION SHIFT LEVER BALL SEAT) |
| 33556F | Seat, Transmission Shift Lever Ball |
| 33602B | Bushing (FOR SELECT LEVER) |
| 33602C | Bolt (FOR SELECT LEVER) |
| 33602D | Collar (FOR SELECT LEVER) |
| 33602E | Spring, Torsion (FOR SELECT LEVER) |
| 33602F | Lever Sub-assy, Select (FOR FLOOR SHIFT) |
| 33821 | Cable Transmission Control Shift (FOR FLOOR SHIFT) |
| 33822 | Cable Transmission Control Select (FOR FLOOR SHIFT) |
| 33823 | Bracket, Transmission Control Cable, NO.1 |
| 38968 | Protector, Control Cable |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
