Toyota Van
1983-08 → 1988-08 · chassis YR2#,3# · catalogue 651420 · Europe
Discontinued model
Data version 1988-12
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 45201 — Shaft Sub-assy, Steering Main | ||||
| 45210-22050 note |
Shaft Sub-assy, Steering Main
1984-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45210-22050 note |
Shaft Sub-assy, Steering Main
1983-08 → 1984-08
ended
|
YR21;YR27 USA | — | |
| 45210-28021 |
Shaft Sub-assy, Steering Main
1983-08 → 1985-08
ended
|
YR2# DLX,STD | — | |
| 45210-28040 |
Shaft Sub-assy, Steering Main
1985-08 → 1988-08
ended
|
YR2#,3# DLX,STD | — | |
| 45201A — Bearing(FOR STEERING MAIN SHAFT) | ||||
| 90363-18001 note |
Bearing(FOR STEERING MAIN SHAFT)
1983-08 → 1984-08
ended
|
YR21;YR27 USA | — | |
| 90363-18001 note |
Bearing(FOR STEERING MAIN SHAFT)
1984-08 → 1988-08
ended
|
YR2#,3# | — | |
| 90363-18038 |
Bearing(FOR STEERING MAIN SHAFT)
1983-08 → 1985-08
ended
|
YR2# DLX,STD | — | |
| 90363-18038 |
Bearing(FOR STEERING MAIN SHAFT)
1985-08 → 1988-08
ended
|
YR2#,3# DLX,STD | — | |
| 90363-28001 note |
Bearing(FOR STEERING MAIN SHAFT)
1983-08 → 1984-08
ended
|
YR21;YR27 USA | — | |
| 90363-28001 note |
Bearing(FOR STEERING MAIN SHAFT)
1984-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45201B — Ring, Shaft Snap(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
1983-08 → 1988-08
ended
|
YR2#,3# | — | |
| 90520-17269 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
1983-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45201G — Spring, Compression(FOR STEERING MAIN SHAFT) | ||||
| 90501-45011 |
Spring, Compression(FOR STEERING MAIN SHAFT)
1983-08 → 1984-08
ended
|
YR21;YR27 USA | — | |
| 90501-45011 |
Spring, Compression(FOR STEERING MAIN SHAFT)
1984-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45202 — Shaft Sub-assy, Steering Intermediate | ||||
| 45220-28021 |
Shaft Sub-assy, Steering Intermediate
1983-08 → 1984-08
ended
|
YR21;YR27 USA | — | |
| 45220-28021 |
Shaft Sub-assy, Steering Intermediate
1984-08 → 1985-08
ended
|
YR2# | — | |
| 45220-28050 |
Shaft Sub-assy, Steering Intermediate
1985-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45202B — Ring, Shaft Snap(FOR STEERING INTERMEDIATE SHAFT) | ||||
| 96152-00300 |
Ring, Shaft Snap(FOR STEERING INTERMEDIATE SHAFT)
1983-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45205 — Tube Sub-assy, Steering Column | ||||
| 45205-28050 note |
Tube Sub-assy, Steering Column
1983-08 → 1984-08
ended
|
YR21;YR27 USA | — | |
| 45205-28050 note |
Tube Sub-assy, Steering Column
1984-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45205-28080 |
Tube Sub-assy, Steering Column
1985-08 → 1988-08
ended
|
YR2#,3# DLX,STD | — | |
| 45205-28080 |
Tube Sub-assy, Steering Column
1983-08 → 1985-08
ended
|
YR2# DLX,STD | — | |
| 45215 — Collar, Main Shaft Bearing Thrust | ||||
| 45215-22011 |
Collar, Main Shaft Bearing Thrust
1983-08 → 1984-08
ended
|
YR21;YR27 USA | — | |
| 45215-22011 |
Collar, Main Shaft Bearing Thrust
1984-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45224 — Block, Bearing(FOR STEERING FLEXIBLE COUPLING) | ||||
| 45225-26010 note |
Block, Bearing(FOR STEERING FLEXIBLE COUPLING)
1984-06 → 1988-08
ended
|
YR2#,3# | — | |
| 45230 — Coupling Assy, Flexible | ||||
| 45230-14020 note |
Coupling Assy, Flexible
1985-08 → 1988-08
ended
|
YR2# | — | |
| 45230-27020 |
Coupling Assy, Flexible
1985-08 → 1988-08
ended
|
YR2# | — | |
| 45230-28010 |
Coupling Assy, Flexible
1986-08 → 1988-08
ended
|
YR3# | — | |
| 45252 — Tube, Steering Column, Lower | ||||
| 45252-28050 |
Tube, Steering Column, Lower
1983-08 → 1985-08
ended
|
YR2# | — | |
| 45252-28090 |
Tube, Steering Column, Lower
1985-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45263 — Ring, Steering Column, NO.1 | ||||
| 45263-32010 |
Ring, Steering Column, NO.1
1983-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45272 — Clamp, Steering Column, Lower | ||||
| 45272-28030 |
Clamp, Steering Column, Lower
1983-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45275 — Bracket, Steering Column, Upper | ||||
| 45280-28080 |
Bracket, Steering Column, Upper
1983-08 → 1985-08
ended
|
YR2# DLX,STD | — | |
| 45280-28080 |
Bracket, Steering Column, Upper
1985-08 → 1987-08
ended
|
YR2#,32 DLX,STD | — | |
| 45280-28081 |
Bracket, Steering Column, Upper
1987-08 → 1988-08
ended
|
YR2#,3# DLX,STD | — | |
| 45280-35170 note |
Bracket, Steering Column, Upper
1983-08 → 1984-08
ended
|
YR21;YR27 USA | — | |
| 45280-35170 note |
Bracket, Steering Column, Upper
1984-08 → 1987-08
ended
|
YR2#,3# | — | |
| 45280-35171 note |
Bracket, Steering Column, Upper
1987-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45292 — Seal, Main Shaft Lower Dust | ||||
| 45292-28010 |
Seal, Main Shaft Lower Dust
1983-08 → 1988-08
ended
|
YR2#,3# | — | |
| 45390 — Shaft Assy, Steering Torque | ||||
| 45390-28010 |
Shaft Assy, Steering Torque
1985-08 → 1988-08
ended
|
YR2# | — | |
| 45390-28020 note |
Shaft Assy, Steering Torque
1985-08 → 1988-08
ended
|
YR2# | — | |
| 45390-28030 |
Shaft Assy, Steering Torque
1986-08 → 1988-08
ended
|
YR3# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
