Toyota Van
1983-08 → 1988-08 · chassis YR2#,3# · catalogue 651420 · Europe
Discontinued model
Data version 1988-12
Side Member
79 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 58741B | Protector, Quarter Panel, RH |
| 58742B | Protector, Quarter Panel, LH |
| 58743 | Protecter, Slide Door Panel, RH |
| 61107 | Pillar Sub-assy, Front Body Outer, RH |
| 61108 | Pillar Sub-assy, Front Body Outer, LH |
| 61135 | Reinforcement, Front Body Pillar, Upper RH |
| 61136 | Reinforcement, Front Body Pillar, Upper LH |
| 61163 | Pillar, Front Body, Inner RH |
| 61164 | Pillar, Front Body, Inner LH |
| 61167B | Brace, Front Body Pillar, Lower |
| 61201 | Rail Sub-assy, Roof Side, RH |
| 61211 | Rail, Roof Side, Outer RH |
| 61212 | Rail, Roof Side, Outer LH |
| 61231 | Rail, Roof Side, Inner RH |
| 61232 | Rail, Roof Side, Inner LH |
| 61233A | Rail, Roof Side, Inner NO.2 RH |
| 61261 | Channel, Roof Drip, RH |
| 61262 | Channel, Roof Drip, LH |
| 61263B | Channel, Roof Drip Side, Front RH |
| 61264A | Channel, Roof Drip Side, Front LH |
| 61267A | Channel, Roof Drip Side, Rear RH |
| 61268 | Channel, Roof Drip Side, Rear LH |
| 61281 | Bracket, Sliding Roof Housing Mounting, NO.1 |
| 61283 | Bracket, Sliding Roof Housing Mounting, NO.3 RH |
| 61284 | Bracket, Sliding Roof Housing Mounting, NO.3 LH |
| 61285 | Bracket, Sliding Roof Housing Side |
| 61301B | Pillar, Center Body, Outer RH |
| 61307 | Pillar Sub-assy, Center Body, Inner RH |
| 61338A | Reinforcement, Center Body Pillar, Inner LH |
| 61353 | Cover, Center Pillar Upper |
| 61401 | Panel Sub-assy, Fender, RH |
| 61402 | Panel Sub-assy, Fender, LH |
| 61411 | Panel, Rocker, Outer RH |
| 61423A | Panel, Fender, Inner Lower RH |
| 61424A | Panel, Fender, Inner Lower LH |
| 61506 | Reinforce Sub-assy, Front Door Lock Striker, LH |
| 61511C | Reinforcement, Quarter Lock Pillar, RH |
| 61512C | Reinforcement, Quarter Lock Pillar, LH |
| 61606 | Frame Sub-assy, Back Door Opening Side, RH |
| 61607 | Frame Sub-assy, Back Door Opening Side, LH |
| 61611 | Panel, Quarter, RH |
| 61612 | Panel, Quarter, LH |
| 61613A | Extension, Quarter Panel Rear, RH |
| 61614A | Extension, Quarter Panel, Rear LH |
| 61616B | Reinforcement, Quarter Panel, Outer Rear |
| 61619 | Reinforcement, Slide Door Lock Striker |
| 61619A | Reinforcement, Quarter Panel |
| 61619D | Reinforcement, Quarter Panel, RH |
| 61629A | Reinforcement, Quarter Panel, LH |
| 61631A | Panel, Quarter Wheel House, Outer RH |
| 61632A | Panel, Quarter Wheel House, Outer LH |
| 61633A | Panel, Quarter Wheel House, Inner RH |
| 61634A | Panel, Quarter Wheel House, Inner LH |
| 61669A | Retainer, Front Door Open Switch Set |
| 61675A | Reinforce, Seat Belt Anchor, NO.2 Upper RH |
| 61676A | Reinforce, Seat Belt Anchor, NO.2 Upper LH |
| 61693 | Cover, Center Body Pillar Inner |
| 61694 | Cover, Quarter Inner, NO.1 |
| 61707 | Panel Sub-assy, Quarter, Inner RH |
| 61707H | Dust Proof, Center Pillar |
| 61708 | Panel Sub-assy, Quarter, Inner LH |
| 61725 | Box, Fuel Inlet |
| 61743A | Reinforcement, Back Door Opening Side, RH |
| 61744A | Reinforcement, Back Door Opening Side, LH |
| 61745A | Reinforcement, Back Door Opening, Lower RH |
| 61746A | Reinforcement, Back Door Opening, Lower LH |
| 61828A | Bracket, Rear Door Rail, Center RH |
| 62475B | Seal, Roof Side, Inner |
| 62498 | Seal, Roof Side, Inner Rear |
| 62586C | Cover, Quarter Pillar, Lower LH |
| 63168A | Retainer, Roof Reinforcement, NO.1 |
| 63169 | Retainer, Roof Reinforcement, NO.2 |
| 67178 | Retainer, Rear Door Switch, RH |
| 68981A | Retainer, Back Door Stay, RH |
| 68982A | Retainer, Back Door Stay, LH |
| 76603 | Mudguard Sub-assy, Front Fender, RH |
| 76604 | Mudguard Sub-assy, Front Fender, LH |
| 76607 | Mudguard Sub-assy, Quarter Panel, Rear RH |
| 76608 | Mudguard Sub-assy, Quarter Panel, Rear LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
