Toyota Liteace Van Wagon
1992-01 → 1995-01 · chassis CR2#,KR2#,YR2# · catalogue 651540 · Europe
Discontinued model
Data version 1995-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 46304 — Equalizer Sub-assy, Parking Brake | ||||
| 46304-28010 |
Equalizer Sub-assy, Parking Brake
1992-01 → 1995-01
ended
|
CR2#,KR2#,YR2# | — | |
| 46321 — Lever, Parking Brake Intermediate | ||||
| 46321-28060 |
Lever, Parking Brake Intermediate
1992-01 → 1995-01
ended
|
CR2#,KR2#,YR2# | — | |
| 46321A — Spring, Tensiion(FOR PARKING BRAKE INTERMEDIATE LEVER) | ||||
| 90506-11006 |
Spring, Tensiion(FOR PARKING BRAKE INTERMEDIATE LEVER)
1992-01 → 1995-01
ended
|
CR2#,KR2#,YR2# | — | |
| 46356 — Bracket, Equalizer Support | ||||
| 46356-28031 |
Bracket, Equalizer Support
1992-01 → 1995-01
ended
|
CR2#,KR2#,YR2# | — | |
| 46361 — Rod, Parking Brake Pull | ||||
| 46361-28031 |
Rod, Parking Brake Pull
1992-01 → 1995-01
ended
|
CR2#,KR2#,YR2# | — | |
| 46420 — Cable Assy, Parking Brake, NO.2 | ||||
| 46420-28330 |
Cable Assy, Parking Brake, NO.2
1992-01 → 1995-01
ended
|
CR21,KR21,YR22 | — | |
| 46420-28340 |
Cable Assy, Parking Brake, NO.2
1992-01 → 1995-01
ended
|
CR27,KR27,YR29 | — | |
| 46430 — Cable Assy, Parking Brake, NO.3 | ||||
| 46430-28280 |
Cable Assy, Parking Brake, NO.3
1992-01 → 1995-01
ended
|
CR21,KR21,YR22 | — | |
| 46430-28290 |
Cable Assy, Parking Brake, NO.3
1992-01 → 1995-01
ended
|
CR27,KR27,YR29 | — | |
| 46441 — Nut, Wire Adjusting, NO.1 | ||||
| 46441-35010 |
Nut, Wire Adjusting, NO.1
1992-01 → 1995-01
ended
|
CR2#,KR2#,YR2# | — | |
| 46452 — Bracket, Parking Brake Cable Support, NO.2 | ||||
| 46452-28060 |
Bracket, Parking Brake Cable Support, NO.2
1992-01 → 1995-01
ended
|
CR2#,KR2#,YR2# | — | |
| 46453A — Bracket, Cable Support, NO.3 | ||||
| 46453-28010 |
Bracket, Cable Support, NO.3
1992-01 → 1995-01
ended
|
CR2#,KR2#,YR2# | — | |
| 46458A — Retainer, Cable | ||||
| 46458-28010 |
Retainer, Cable
1992-01 → 1995-01
ended
|
CR2#,KR2#,YR2# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
