Toyota Previa
1990-05 → 1999-12 · chassis TCR1#,2# · catalogue 652240 · Europe
Discontinued model
Data version 2000-07
Front Door Panel & Glass
64 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 55539M | Cover, Spare Switch Hole |
| 55547 | Cover, Remote Control Mirror Hole |
| 62110 | Window Assy, Front Side Fix, RH |
| 62120A | Window Assy, Front Side Fix, LH |
| 62124 | Fastener, Front Side Window Fix, RH |
| 62124A | Fastener, Front Side Window Fix, LH |
| 67001 | Panel Sub-assy, Front Door, RH |
| 67002 | Panel Sub-assy, Front Door, LH |
| 67111 | Panel, Front Door, Outer RH |
| 67112 | Panel, Front Door, Outer LH |
| 67118B | Retainer, Outer Rear View Mirror, RH |
| 67119 | Retainer, Outer Rear View Mirror, LH |
| 67401F | Frame Sub-assy, Front Door, Front Lower RH |
| 67402F | Frame Sub-assy, Front Door, Front Lower LH |
| 67403F | Frame Sub-assy, Front Door, Rear Lower RH |
| 67404F | Frame Sub-assy, Front Door, Rear Lower LH |
| 67485C | Seal, Front Door Bracket, NO.1 |
| 67485D | Seal, Front Door Bracket, NO.2 |
| 67601 | Board Sub-assy, Front Door Trim, RH |
| 67601A | Retainer(FOR FRONT DOOR TRIM BOARD) |
| 67602 | Board Sub-assy, Front Door Trim, LH |
| 67625A | Bracket, Front Door Trim, NO.1 |
| 67626A | Bracket, Door Trim, NO.2 |
| 67701 | Cover Sub-assy, Front Door Trim, RH |
| 67702 | Cover Sub-assy, Front Door Trim, LH |
| 67762 | Cover, Front Door Lower Trim |
| 67779 | Cap, Front Door Trim Pocket |
| 67811 | Pad, Front Door Silencer |
| 67815 | Duct, Door Ventilation, RH |
| 67825A | Duct, Door Ventilation, LH |
| 67829A | Seal, Front Door Wire Hole |
| 67831 | Cover, Front Door Service Hole, RH |
| 67832 | Cover, Front Door Service Hole, LH |
| 67833D | Cover, Front Door Service Hole, NO.2 RH |
| 67834 | Cover, Front Door Service Hole, NO.2 LH |
| 67861 | Weatherstrip, Front Door, RH |
| 67862 | Weatherstrip, Front Door, LH |
| 67863B | Weatherstrip, Front Door, NO.2 RH |
| 67864B | Weatherstrip, Front Door, NO.2 LH |
| 67865B | Weatherstrip, Front Door, NO.3 RH |
| 67866A | Weatherstrip, Front Door, NO.3 LH |
| 67867C | Retainer, Front Door Weatherstrip, RH |
| 67867G | Retainer, Door Weatherstrip, RH |
| 67868A | Clip, Door Glass Weatherstrip(FOR FRONT DOOR) |
| 67868C | Retainer, Front Door Weatherstrip, LH |
| 67868L | Retainer, Door Weatherstrip, LH |
| 68101 | Glass Sub-assy, Front Door, RH |
| 68102 | Glass Sub-assy, Front Door, LH |
| 68141B | Clip, Door Glass Run |
| 68141E | Run, Front Door Glass, RH |
| 68143A | Run, Front Door Glass, NO.2 |
| 68151D | Run, Front Door Glass, LH |
| 68160C | Weatherstrip Assy, Front Door Glass, Outer RH |
| 68161A | Clip(FOR FRONT DOOR GLASS OUTER WEATHERSTRIP) |
| 68170 | Weatherstrip Assy, Front Door Glass, Inner |
| 68194B | Seal, Front Door Belt, Rear RH |
| 68195B | Seal, Front Door Belt, Rear LH |
| 68210C | Weatherstrip Assy, Front Door Glass, Outer LH |
| 68211D | Clip, Door Glass Weatherstrip |
| 68610 | Check Assy, Front Door |
| 68617 | Pin, Front Door Check |
| 74201B | Panel Sub-assy, Front Armrest, Upper RH |
| 74202B | Panel Sub-assy, Front Armrest, Upper LH |
| 74697 | Plug, Door Assist Grip, RH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
