Toyota Previa/Tarago
2000-02 → 2006-01 · chassis ACR30,CLR30 · catalogue 652250 · Europe
Discontinued model
Data version 2006-09
Meter
17 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 83100 | Meter Assy, Combination |
| 83100B | Bulb, Combination Meter, NO.1 |
| 83101 | Socket Sub-assy, Combination Meter Bulb |
| 83102 | Plate Sub-assy, Combination Meter Circuit, NO.1 |
| 83129 | Wire, Meter |
| 83133 | Plate, Combination Meter, NO.1 |
| 83133A | Plate, Combination Meter, NO.2 |
| 83133B | Plate, Combination Meter, NO.3 |
| 83134 | Cover, Combination Meter, NO.1 |
| 83138G | Glass, Combination Meter |
| 83291 | Computer, Combination Meter |
| 83910 | Clock Assy |
| 83950F | Lamp Assy, Telltale |
| 83950G | Bulb, Telltale Lamp |
| 83950L | Socket, Telltale Lamp |
| 83959A | Plate, Telltale Lamp Circuit |
| 89820 | Sensor Assy, Inclination |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
