Toyota RAV4 (JPP)
2018-11 → present · chassis AXAA5#,AXAH5#,AXAL5#,MXAA5# · catalogue 662250 · Europe
Supported model
Data version 2023-10
Side Member
73 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 53821B | Bracket, Front Fender, Rear RH |
| 53822B | Bracket, Front Fender, Rear LH |
| 53837C | Bracket, Front Side Panel, NO.2 RH |
| 53838E | Bracket, Front Side Panel, NO.2 LH |
| 61035B | Pillar Sub-assy, NO.4 Inner, RH |
| 61037A | Reinforcement Sub-assy, Center Body Pillar, RH |
| 61038A | Reinforcement Sub-assy, Center Body Pillar, LH |
| 61045A | Pillar Sub-assy, NO.4 Inner, LH |
| 61063A | Extension Sub-assy, Rear Wheel Opening, NO.2 RH |
| 61064A | Extension Sub-assy, Rear Wheel Opening, NO.2 LH |
| 61103A | Reinforcement Sub-assy, Cowl Side, RH |
| 61104B | Reinforcement Sub-assy, Cowl Side, LH |
| 61108A | Reinforce Sub-assy, Front Body Pillar, Lower RH |
| 61109A | Reinforce Sub-assy, Front Body Pillar, Lower LH |
| 61113A | Panel, Side, Outer NO.2 RH |
| 61114B | Panel, Side, Outer NO.2 LH |
| 61121D | Panel, Cowl Side, RH |
| 61122D | Panel, Cowl Side, LH |
| 61131 | Pillar, Front Body, Upper Outer RH |
| 61132 | Pillar, Front Body, Upper Outer LH |
| 61201 | Rail Sub-assy, Roof Side, RH |
| 61202 | Rail Sub-assy, Roof Side, LH |
| 61203 | Rail Sub-assy, Roof Side, Inner RH |
| 61204 | Rail Sub-assy, Roof Side, Inner LH |
| 61207A | Rail Sub-assy, Roof Side, Inner NO.3 RH |
| 61208A | Rail Sub-assy, Roof Side, Inner NO.3 LH |
| 61211 | Rail, Roof Side, Outer RH |
| 61212 | Rail, Roof Side, Outer LH |
| 61213B | Rail, Roof Side, Outer NO.2 RH |
| 61214B | Rail, Roof Side, Outer NO.2 LH |
| 61241A | Gusset, Roof Side Rail, Rear RH |
| 61242A | Gusset, Roof Side Rail, Rear LH |
| 61311B | Pillar, Center Body, Outer RH |
| 61312B | Pillar, Center Body, Outer LH |
| 61401C | Panel Sub-assy, Rocker, Outer RH |
| 61402C | Panel Sub-assy, Rocker, Outer LH |
| 61607H | Panel Sub-assy, Quarter Wheel House, Inner RH |
| 61608H | Panel Sub-assy, Quarter Wheel House, Inner LH |
| 61611 | Panel, Quarter, RH |
| 61612 | Panel, Quarter, LH |
| 61615F | Reinforcement, Quarter Panel, Outer RH |
| 61616E | Reinforcement, Quarter Panel, Outer LH |
| 61617A | Panel, Quarter Inner, Rear RH |
| 61618A | Panel, Quarter, Inner Rear LH |
| 61621D | Trough, Back Door Opening, RH |
| 61622D | Trough, Back Door Opening, LH |
| 61627B | Extension, Quarter Panel, Upper Rear RH |
| 61628B | Extension, Quarter Panel, Upper Rear LH |
| 61631A | Panel, Quarter Wheel House, Outer RH |
| 61632A | Panel, Quarter Wheel House, Outer LH |
| 61637D | Reinforcement, Quarter, Inner RH |
| 61638D | Reinforcement, Quarter, Inner LH |
| 61703H | Reinforcement Sub-assy, Roof Side, Inner RH |
| 61704J | Reinforcement Sub-assy, Roof Side, Inner LH |
| 61708A | Reinforcement Sub-assy, Seat Belt Anchor, RH |
| 61709A | Reinforcement Sub-assy, Seat Belt Anchor, LH |
| 61711 | Panel, Roof Side, Outer RH |
| 61712 | Panel, Roof Side, Outer LH |
| 61713B | Reinforce, Roof Side, Outer RH |
| 61714B | Reinforce, Roof Side, Outer LH |
| 61717A | Reinforcement, Quarter Panel Extension, RH |
| 61718A | Reinforcement, Quarter Panel Extension, LH |
| 61731B | Panel, Roof Side, Inner RH |
| 61732B | Panel, Roof Side, Inner LH |
| 61745A | Reinforcement, Back Door Opening, Lower RH |
| 61746A | Reinforcement, Back Door Opening, Lower LH |
| 61826C | Pad, Noise Shutter, NO.3 |
| 62151B | Pad, Cowl Side Silencer |
| 62554B | Pad, Pillar, NO.4 |
| 65565 | Patch, Side Panel Rear End, RH |
| 65566 | Patch, Side Panel Rear End, LH |
| 65637B | Liner, Rear Wheel House, RH |
| 65638A | Liner, Rear Wheel House, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
