Toyota RAV4
1995-11 → 2000-08 · chassis SXA1# · catalogue 662410 · Europe
Discontinued model
Data version 2001-03
Moulding
47 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 53852A | Pad, Front Wheel Opening Extension, NO.2 |
| 53853B | Pad, Front Wheel Opening Extension, NO.1 |
| 61629B | Extension, Quarter Outer Panel, RR |
| 61629C | Extension, Quarter Outer Panel, RR |
| 61667F | Seal, Quarter Panel |
| 61783F | Pad, Rear Wheel Opening Extension NO.1 |
| 61783H | Pad, Reae Wheel Opening Extension, NO.2 |
| 61785G | Pad, Rear Wheel Opening Extension, NO.3 |
| 61788D | Pad, Rear Wheel Opening Extension Pad NO.4 |
| 63107D | Bracket Sub-assy, Roof Moulding |
| 68211G | Clip(DOOR BELT MOULDING RH) |
| 68212D | Clip(DOOR BELT MOULDING LH) |
| 75071A | Moulding Sub-assy, Front Door, Outside RH |
| 75072A | Moulding Sub-assy, Front Door, Outside LH |
| 75075 | Moulding Sub-assy, Rear Door, Outside RH |
| 75076 | Moulding Sub-assy, Rear Door, Outside LH |
| 75395A | Clip, Outside Moulding, NO.1 |
| 75396A | Clip, Outside Moulding, NO.2 |
| 75396B | Clip, Outside Moulding, NO.2 |
| 75498D | Clip, Quarter Garnish, NO.1 |
| 75505A | Moulding Sub-assy, Roof Drip Side Finish, RH |
| 75506A | Moulding Sub-assy, Roof Drip Side Finish, LH |
| 75533E | Moulding, Windshield, Outside |
| 75561 | Clip, Roof Drip Side Finish Moulding, NO.1 |
| 75562 | Clip, Roof Drip Side Finish Moulding, NO.2 |
| 75571 | Moulding, Back Window, Outside Upper |
| 75595C | Pad, Quarter Garnish, Upper |
| 75601A | Moulding Sub-assy, Front Fender, RH |
| 75602A | Moulding Sub-assy, Front Fender, LH |
| 75651 | Moulding, Quarter, Outside RH |
| 75652 | Moulding, Quarter, Outside LH |
| 75695 | Pad, Quarter Outside Moulding |
| 75696 | Pad, Body Outside Moulding, NO.1 |
| 75699 | Pad, Body Outside Moulding, NO.4 |
| 75710 | Moulding Assy, Front Door Belt, RH |
| 75720 | Moulding Assy, Front Door Belt, LH |
| 75730 | Moulding Assy, Rear Door Belt, RH |
| 75740 | Moulding Assy, Rear Door Belt, LH |
| 75793 | Pad, Front Door Outside Moulding, Upper |
| 75869B | Retainer, Quarter Opening, LH |
| 75879A | Retainer, Quarter Opening, RH |
| 75991G | Stripe, Quarter, Front RH |
| 75992F | Stripe, Quarter, Front LH |
| 75993E | Stripe, Quarter, Rear RH |
| 75994F | Stripe, Quarter, Rear LH |
| 76927B | Protector, Rear Mudguard, RH |
| 76928B | Protector, Rear Mudguard, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
