Toyota RAV4
2000-08 → 2005-11 · chassis ACA2# · catalogue 662420 · Europe
Discontinued model
Data version 2006-06
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 04438F — Boot Kit, Front Drive Shaft, IN & Outboard, RH | ||||
| 04438-28051 |
Boot Kit, Front Drive Shaft, IN & Outboard, RH
2000-08 → 2002-07
ended
|
ACA26 | — | |
| 04438-28052 |
Boot Kit, Front Drive Shaft, IN & Outboard, RH
2002-07 → 2003-07
ended
|
ACA26 | — | |
| 04438-42080 |
Boot Kit, Front Drive Shaft, IN & Outboard, RH
2000-08 → 2002-07
ended
|
ACA21 | — | |
| 04438-42081 |
Boot Kit, Front Drive Shaft, IN & Outboard, RH
2002-07 → 2003-07
ended
|
ACA21 | — | |
| 04427-42050 |
Boot Kit, Front Drive Shaft, IN & Outboard, RH
2005-03 → —
|
ACA23 | — | |
| 04427-42060 |
Boot Kit, Front Drive Shaft, IN & Outboard, RH
2005-03 → —
|
ACA28 | — | |
| 04438-28052 |
Boot Kit, Front Drive Shaft, IN & Outboard, RH
2003-07 → 2005-03
ended
|
ACA28 | — | |
| 04438-42081 |
Boot Kit, Front Drive Shaft, IN & Outboard, RH
2003-07 → 2005-03
ended
|
ACA23 | — | |
| 04438G — Boot Kit, Front Drive Shaft Inboard Joint, RH | ||||
| 04438-28040 |
Boot Kit, Front Drive Shaft Inboard Joint, RH
2000-08 → 2002-07
ended
|
ACA26 | — | |
| 04438-28041 |
Boot Kit, Front Drive Shaft Inboard Joint, RH
2002-07 → 2003-07
ended
|
ACA26 | — | |
| 04438-42070 |
Boot Kit, Front Drive Shaft Inboard Joint, RH
2000-08 → 2002-07
ended
|
ACA21 | — | |
| 04438-42071 |
Boot Kit, Front Drive Shaft Inboard Joint, RH
2002-07 → 2003-07
ended
|
ACA21 | — | |
| 04437-42040 |
Boot Kit, Front Drive Shaft Inboard Joint, RH
2005-03 → —
|
ACA23 | — | |
| 04438-28041 |
Boot Kit, Front Drive Shaft Inboard Joint, RH
2003-07 → 2005-03
ended
|
ACA28 | — | |
| 04438-42071 |
Boot Kit, Front Drive Shaft Inboard Joint, RH
2003-07 → 2005-03
ended
|
ACA23 | — | |
| 04438-42180 |
Boot Kit, Front Drive Shaft Inboard Joint, RH
2005-03 → —
|
ACA28 | — | |
| 41336D — Cover, Front Drive Shaft Dust, RH | ||||
| 41336-12020 |
Cover, Front Drive Shaft Dust, RH
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 41336-21010 |
Cover, Front Drive Shaft Dust, RH
2000-08 → 2003-07
ended
|
ACA21 | — | |
| 41336-12020 |
Cover, Front Drive Shaft Dust, RH
2003-07 → —
|
ACA28 | — | |
| 41336-21010 |
Cover, Front Drive Shaft Dust, RH
2003-07 → —
|
ACA23 | — | |
| 43030 — Joint Assy, Front Drive Inboard, RH | ||||
| 43030-28010 |
Joint Assy, Front Drive Inboard, RH
2000-08 → 2002-07
ended
|
ACA26 | — | |
| 43030-28011 |
Joint Assy, Front Drive Inboard, RH
2002-08 → 2003-07
ended
|
ACA26 | — | |
| 43030-42020 |
Joint Assy, Front Drive Inboard, RH
2000-08 → 2002-07
ended
|
ACA21 | — | |
| 43030-42021 |
Joint Assy, Front Drive Inboard, RH
2002-08 → 2003-07
ended
|
ACA21 | — | |
| 43030-28011 |
Joint Assy, Front Drive Inboard, RH
2003-07 → —
|
ACA28 | — | |
| 43030-42021 |
Joint Assy, Front Drive Inboard, RH
2003-07 → —
|
ACA23 | — | |
| 43045 — Case Sub Assy, Drive Shaft Bearing | ||||
| 43045-20050 |
Case Sub Assy, Drive Shaft Bearing
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 43045-20050 |
Case Sub Assy, Drive Shaft Bearing
2003-07 → 2004-08
ended
|
ACA28 | — | |
| 43045-64020 |
Case Sub Assy, Drive Shaft Bearing
2004-09 → —
|
ACA28 | — | |
| 43045A — Ring, Snap (FOR CASE SUB ASSY, DRIVE SHAFT BEARING) | ||||
| 90520-69002 |
Ring, Snap (FOR CASE SUB ASSY, DRIVE SHAFT BEARING)
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 90520-69002 |
Ring, Snap (FOR CASE SUB ASSY, DRIVE SHAFT BEARING)
2003-07 → —
|
ACA28 | — | |
| 43410 — Shaft Assy, Front Drive, RH | ||||
| 43410-42060 note |
Shaft Assy, Front Drive, RH
2000-08 → 2003-07
ended
|
ACA21 | — | |
| 43410-42070 |
Shaft Assy, Front Drive, RH
2000-08 → 2003-07
ended
|
ACA21 | — | |
| 43410-42080 note |
Shaft Assy, Front Drive, RH
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 43410-42090 |
Shaft Assy, Front Drive, RH
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 43410-42060 note |
Shaft Assy, Front Drive, RH
2003-07 → —
|
ACA23 | — | |
| 43410-42070 |
Shaft Assy, Front Drive, RH
2003-07 → —
|
ACA23 CND | — | |
| 43410-42080 note |
Shaft Assy, Front Drive, RH
2003-07 → —
|
ACA28 | — | |
| 43410-42090 |
Shaft Assy, Front Drive, RH
2003-07 → —
|
ACA28 ATM | — | |
| 43410C — Bearing (FOR FRONT DRIVE SHAFT) | ||||
| 90363-41002 |
Bearing (FOR FRONT DRIVE SHAFT)
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 90363-41002 |
Bearing (FOR FRONT DRIVE SHAFT)
2003-07 → 2004-08
ended
|
ACA28 | — | |
| 90363-41003 |
Bearing (FOR FRONT DRIVE SHAFT)
2004-09 → —
|
ACA28 | — | |
| 43410G — Pin, Straight (FOR FRONT DRIVE SHAFT) | ||||
| 90250-06003 |
Pin, Straight (FOR FRONT DRIVE SHAFT)
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 90250-06003 |
Pin, Straight (FOR FRONT DRIVE SHAFT)
2003-07 → —
|
ACA28 | — | |
| 43410M — Oil Seal, Front Drive Shaft, RH | ||||
| 90311-40025 |
Oil Seal, Front Drive Shaft, RH
2000-08 → 2003-07
ended
|
ACA26 MTM | — | |
| 90311-40026 |
Oil Seal, Front Drive Shaft, RH
2000-08 → 2003-07
ended
|
ACA26 ATM | — | |
| 90311-40025 |
Oil Seal, Front Drive Shaft, RH
2003-07 → 2005-09
ended
|
ACA28 MTM | — | |
| 90311-40026 |
Oil Seal, Front Drive Shaft, RH
2003-07 → 2005-11
ended
|
ACA28 ATM | — | |
| 90311-40030 |
Oil Seal, Front Drive Shaft, RH
2005-09 → 2005-11
ended
|
ACA28 MTM | — | |
| 43410N — Ring, Hole Snap (FOR FRONT DRIVE SHAFT RH) | ||||
| 90520-38015 |
Ring, Hole Snap (FOR FRONT DRIVE SHAFT RH)
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 90521-26004 |
Ring, Hole Snap (FOR FRONT DRIVE SHAFT RH)
2000-08 → 2003-07
ended
|
ACA21 | — | |
| 90520-38015 |
Ring, Hole Snap (FOR FRONT DRIVE SHAFT RH)
2003-07 → —
|
ACA28 | — | |
| 90521-26004 |
Ring, Hole Snap (FOR FRONT DRIVE SHAFT RH)
2003-07 → —
|
ACA23 | — | |
| 43411E — Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT INNER RH) | ||||
| 43425-28010 |
Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT INNER RH)
2000-08 → 2003-07
ended
|
ACA2# | — | |
| 43425-28010 |
Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT INNER RH)
2003-07 → —
|
ACA2# | — | |
| 43447C — Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT RH) | ||||
| 42345-20040 |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT RH)
2000-08 → 2003-07
ended
|
ACA2# | — | |
| 42345-20040 |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT RH)
2003-07 → —
|
ACA2# | — | |
| 43447D — Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT RH) | ||||
| 42345-28020 |
Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT RH)
2000-08 → 2003-07
ended
|
ACA2# | — | |
| 42345-28020 |
Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT RH)
2003-07 → —
|
ACA2# | — | |
| 43448C — Clamp (FOR FRONT AXLE INBOARD JOINT BOOT RH) | ||||
| 42345-42010 note |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT RH)
2002-04 → 2003-07
ended
|
ACA2# | — | |
| 90949-01559 |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT RH)
2000-08 → 2002-04
ended
|
ACA2# | — | |
| 90949-01559 note |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT RH)
2002-04 → 2003-07
ended
|
ACA2# | — | |
| 42345-42010 note |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT RH)
2003-07 → —
|
ACA2# | — | |
| 90949-01559 note |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT RH)
2003-07 → —
|
ACA2# | — | |
| 43448E — Clamp, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT RH) | ||||
| 42345-12160 |
Clamp, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT RH)
2002-03 → 2003-07
ended
|
ACA2# | — | |
| 90949-01076 |
Clamp, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT RH)
2000-08 → 2002-03
ended
|
ACA2# | — | |
| 42345-12160 |
Clamp, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT RH)
2003-07 → —
|
ACA2# | — | |
| 43457 — Bracket, Drive Shaft Bearing | ||||
| 43457-28020 |
Bracket, Drive Shaft Bearing
2000-08 → 2003-07
ended
|
ACA26 ATM | — | |
| 43457-42010 |
Bracket, Drive Shaft Bearing
2000-08 → 2003-07
ended
|
ACA26 MTM | — | |
| 43457-28020 |
Bracket, Drive Shaft Bearing
2003-07 → —
|
ACA28 ATM | — | |
| 43457-42010 |
Bracket, Drive Shaft Bearing
2003-07 → —
|
ACA28 MTM | — | |
| 43457A — Bolt (FOR DRIVE SHAFT BEARING BRACKET SETTING NO.1) | ||||
| 90105-10285 note |
Bolt (FOR DRIVE SHAFT BEARING BRACKET SETTING NO.1)
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 90105-10361 note |
Bolt (FOR DRIVE SHAFT BEARING BRACKET SETTING NO.1)
2003-07 → —
|
ACA28 | — | |
| 43457D — Bolt(FOR DRIVE SHAFT BEARRING BRACKET SETTING NO.2) | ||||
| 90105-10381 |
Bolt(FOR DRIVE SHAFT BEARRING BRACKET SETTING NO.2)
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 90105-10381 |
Bolt(FOR DRIVE SHAFT BEARRING BRACKET SETTING NO.2)
2003-07 → —
|
ACA28 | — | |
| 43458 — Cover, Front Drive Shaft Dust | ||||
| 43458-12010 |
Cover, Front Drive Shaft Dust
2000-08 → 2003-07
ended
|
ACA26 | — | |
| 43458-12010 |
Cover, Front Drive Shaft Dust
2003-07 → —
|
ACA28 | — | |
| 43460 — Shaft Assy, Front Drive Outboard Joint, RH | ||||
| 43460-49065 note |
Shaft Assy, Front Drive Outboard Joint, RH
2000-08 → 2001-01
ended
|
ACA2# | — | |
| 43460-49075 |
Shaft Assy, Front Drive Outboard Joint, RH
2000-08 → 2002-07
ended
|
ACA2# | — | |
| 43460-49076 |
Shaft Assy, Front Drive Outboard Joint, RH
2002-07 → 2003-07
ended
|
ACA2# | — | |
| 43460-49165 note |
Shaft Assy, Front Drive Outboard Joint, RH
2001-01 → 2002-07
ended
|
ACA2# | — | |
| 43460-49167 note |
Shaft Assy, Front Drive Outboard Joint, RH
2002-07 → 2003-07
ended
|
ACA2# | — | |
| 43460-49167 |
Shaft Assy, Front Drive Outboard Joint, RH
2003-07 → 2005-03
ended
|
ACA2# | — | |
| 43460-49325 |
Shaft Assy, Front Drive Outboard Joint, RH
2005-03 → —
|
ACA23 CND | — | |
| 43460-49335 note |
Shaft Assy, Front Drive Outboard Joint, RH
2005-03 → —
|
ACA23 | — | |
| 43460-49345 |
Shaft Assy, Front Drive Outboard Joint, RH
2005-03 → —
|
ACA28 ATM | — | |
| 43460-49365 note |
Shaft Assy, Front Drive Outboard Joint, RH
2005-03 → —
|
ACA28 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
