Toyota RAV4

2020-06 → present · chassis AXAP54 · catalogue 666210 · Europe

Supported model Data version 2023-10
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Cowl Panel & Windshield Glass

22 part groups · 2 illustrations

Illustrations

Figure 554611B 554611B 2020-06 → — Figure 554612B 554612B 2020-06 → —

Part groups

PNCDescription
53383 Seal, Hood TO Cowl Top
53866J Seal, Front Fender TO Cowl Side, RH
53867H Seal, Front Fender TO Cowl Side, LH
55700B Cowl Assy
55704B Panel Sub-assy, Cowl Ventilator
55705B Panel Sub-assy, Cowl Top Side, RH
55706B Panel Sub-assy, Cowl Top Side, LH
55708 Louver Sub-assy, Cowl Top Ventilator
55708C Clip, Cowl Top Ventilator Louver
55752 Shield, Cowl Ventilator Splash
55783B Louver, Cowl Top Ventilator, Center NO.1
55787C Insulator, Cowl Top Panel, NO.1
55787H Clip, Cowl Top Panel Insulator
56111 Glass, Windshield
56115A Stopper, Windshield Glass, NO.1
56116C Stopper, Windshield Glass, NO.2
56117A Dam, Window Glass Adhesive
56153C Moulding, Front Window, Inner Center
56165 Cover, Front Window Inner Moulding, LH
75533G Moulding, Windshield, Outside
75545M Clip, Windshield Outside Moulding
75547F Clip, Windshield Outside Moulding
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
