Toyota Hilux
1972-05 → 1978-07 · chassis RN2# · catalogue 671220 · Europe
Discontinued model
Data version 1978-08
Center Support & Planetary Sun Gear (ATM)
32 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 35079 | Race Sub-assy, 1 Way Clutch, Outer |
| 35079A | Ring, Hole Snap(FOR CLUTCH RACE SET) |
| 35620 | Support Assy, Center |
| 35620A | Plate, Clutch (FOR BRAKE) |
| 35620B | Disc, Clutch (FOR BRAKE) |
| 35620C | Flange, Clutch (FOR BRAKE) |
| 35620D | Ring (FOR BRAKE) |
| 35620R | Plate, Clutch (FOR REAR BRAKE) |
| 35620S | Disc, Clutch (FOR REAR BRAKE) |
| 35620T | Flange, Clutch (FOR REAR BRAKE) |
| 35620U | Ring (FOR REAR BRAKE) |
| 35621 | Piston, Brake, NO.1 |
| 35621A | Ring, O (FOR BRAKE PISTON OUTER) |
| 35621B | Ring, O (FOR BRAKE PISTON INNER) |
| 35621C | Spring (FOR BRAKE PISTON RETURN) |
| 35621R | Piston, Brake (FOR REAR BRAKE) |
| 35621S | Ring (FOR REAR BRAKE PISTON OUTER) |
| 35621T | Ring (FOR REAR BRAKE PISTON INNER) |
| 35621U | Spring (FOR REAR BRAKE PISTON RETURN) |
| 35627 | Seat, Brake Return Spring |
| 35627A | Ring, Shaft Snap (FOR BRAKE RETURN SPRING SEAT) |
| 35627R | Seat, Brake Return Spping (FOR REAR BRAKE) |
| 35627S | Ring, Shaft Snap (FOR REAR BRAKE RETURN SPRING SEAT) |
| 35662 | Hub, Brake |
| 35709 | Support Sub-assy, Center |
| 35709A | Plug, Straight (FOR CENTER SUPPORT) |
| 35709B | Ring, O (FOR CENTER SUPPORT) |
| 35709C | Ring, Oil Seal (FOR CENTER SUPPORT) |
| 35785 | Retainer, Center Support Ring |
| 35790 | Clutch Assy, 1 Way |
| 35793 | Retainer, 1 Way Clutch |
| 35798 | Bolt, Center Support, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
