Toyota Hilux
1983-08 → 1998-07 · chassis LN5#,6#,YN5#,6#,RN5#,6# · catalogue 671240 · Europe
Discontinued model
Data version 1999-01
Moulding
47 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 75531 | Moulding, Windshield, Outer Upper |
| 75531A | Clip, Windshield Moulding Set, NO.1 |
| 75531B | Clip, Windshield Moulding Set, NO.2 |
| 75531C | Clip, Windshield Moulding Set, NO.3 |
| 75532 | Moulding, Windshield, Lower |
| 75532A | Clip, Windshield Moulding Set |
| 75533 | Moulding, Windshield, Outside RH |
| 75533A | Clip, Windshield Side Moulding, RH |
| 75534 | Moulding, Windshield, Outside LH |
| 75534A | Clip, Windshield Side Moulding, LH |
| 75536A | Cover, Windshield Outside Moulding Joint |
| 75548A | Fastener, Windshield Outside Moulding, NO.1 |
| 75553 | Moulding, Roof Drip Side Finish, RH |
| 75554 | Moulding, Roof Drip Side Finish, LH |
| 75555 | Moulding, Roof Drip Side Finish, Rear RH |
| 75556 | Moulding, Roof Drip Side Finish, Rear LH |
| 75603 | Moulding Sub-assy, Quarter Slide Window Outside |
| 75613 | Moulding, Front Fender, Outside RH |
| 75614 | Moulding, Front Fender, Outside LH |
| 75651 | Moulding, Quarter, Outside RH |
| 75651A | Moulding, Quarter Outside, Rear RH, NO.1 |
| 75651B | Moulding, Quarter Outside, Rear RH, NO.2 |
| 75652 | Moulding, Quarter, Outside LH |
| 75652A | Moulding, Quarter Outside, Rear LH, NO.1 |
| 75652B | Moulding, Quarter Outside, Rear LH, NO.2 |
| 75731A | Moulding, Front Door, Outside RH |
| 75732A | Moulding, Front Door, Outside LH |
| 75733 | Moulding, Front Door Window Frame, Rear RH |
| 75734 | Moulding, Front Door Window Frame, Rear LH |
| 75737 | Moulding, Front Door Window Frame, Front RH |
| 75738 | Moulding, Front Door Window Frame, Front LH |
| 75741 | Moulding, Rear Door, Outside RH |
| 75742 | Moulding, Rear Door, Outside LH |
| 75851 | Moulding, Rocker Panel, RH |
| 75851D | Clip(FOR ROCKER PANEL MOULDING SET) |
| 75852 | Moulding, Rocker Panel, LH |
| 75855A | Moulding, Rocker Panel, Rear RH |
| 75856A | Moulding, Rocker Panel, Rear LH |
| 75871 | Moulding, Front Fender Wheel Opening, RH |
| 75872 | Moulding, Front Fender Wheel Opening, LH |
| 75873 | Moulding, Quarter Panel Wheel Opening, RH |
| 75874 | Moulding, Quarter Panel Wheel Opening, LH |
| 75879 | Retainer, Quarter Opening |
| 75951 | Plate, Front Door Scuff, Outside RH |
| 75952 | Plate, Front Door Scuff, Outside LH |
| 75955 | Plate, Rear Door Scuff, Outside RH |
| 75956 | Plate, Rear Door Scuff, Outside LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
