Toyota Fortuner
2020-06 → 2021-08 · chassis GUN156,TGN156 · catalogue 6715C0 · Europe
Supported model
Data version 2020-04
Electronic Fuel Injection System
9 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 85910Z | Relay, Injection (FOR EFI) |
| 85915S | Relay, Heater (FOR AIR FUEL RATIO SENSOR) |
| 89421N | Sensor, Air Pressure |
| 89422 | Sensor, Water Temperature (FOR E.F.I.) |
| 89581B | Driver, Air Injection Control |
| 89661 | Computer, Engine Control |
| 89667 | Bracket, Engine Control Computer |
| 89668 | Bracket, Engine Control Computer, NO.2 |
| 89879A | Bracket, Injector Driver |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
