Toyota Hilux
1997-08 → 2005-08 · chassis KDN1##,LN1##,RZN168,173 · catalogue 672560 · Europe
Discontinued model
Data version 2006-02
Seat & Seat Track
101 part groups · 10 illustrations
Part groups
| PNC | Description |
|---|---|
| 71015 | Frame Sub-assy, Rear Seat Cushion |
| 71015A | Frame Sub-assy, Rear Seat Cushion, RH |
| 71016A | Frame Sub-assy, Rear Seat Cushion, LH |
| 71017A | Frame Sub-assy, Rear Seatback |
| 71071B | Cover, Front Seat Cushion(FOR BENCH TYPE) |
| 71071S | Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71072S | Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71073B | Cover, Front Seatback(FOR BENCH TYPE) |
| 71073S | Cover, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71074S | Cover, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71075B | Cover, Rear Seat Cushion (FOR BENCH TYPE) |
| 71075S | Cover, Rear Seat Cushion, RH (FOR SEPARATE TYPE) |
| 71076S | Cover, Rear Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71077B | Cover, Rear Seatback (FOR BENCH TYPE) |
| 71147 | Silencer, Seat Spring |
| 71311 | Pin, Front Seat Hinge |
| 71311E | Bush(FOR REAR SEAT HINGE PIN) |
| 71331A | Pin, Rear Seat Hinge |
| 71379A | Stopper, Front Seat Vertical Handle |
| 71379C | Stopper, Rear Seat Cushion |
| 71389 | Spacer, Center Seat Hinge |
| 71410B | Cushion Assy, Front Seat(FOR BENCH TYPE) |
| 71410S | Cushion Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71420S | Cushion Assy, Front Seat, LH (FOR SEPARATE TYPE) |
| 71430B | Back Assy, Front Seat(FOR BENCH TYPE) |
| 71430S | Back Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71440S | Back Assy, Front Seat, LH(FOR SEPARATE TYPE) |
| 71460B | Cushion Assy, Rear Seat (FOR BENCH TYPE) |
| 71460S | Cushion Assy, Rear Seat, RH(FOR SEPARATE TYPE) |
| 71470S | Cushion Assy, Rear Seat, LH (FOR SEPARATE TYPE) |
| 71480B | Back Assy, Rear Seat (FOR BENCH TYPE) |
| 71491C | Spring, Rear Seat Set |
| 71511B | Pad, Front Seat Cushion(FOR BENCH TYPE) |
| 71511S | Pad, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71512S | Pad, Front Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71527 | Tape, Front Seat Cushion Silencer |
| 71537A | Protector, Front Seat Cushion |
| 71551B | Pad, Front Seatback(FOR BENCH TYPE) |
| 71551S | Pad, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71552S | Pad, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71561B | Pad, Front Seatback, Upper |
| 71567 | Pad, Front Seatback Safety |
| 71587 | Protector, Front Seatback Edge |
| 71587A | Protector, Rear Seatback Edge |
| 71587B | Protector, Front Seatback Edge |
| 71588 | Protector, Front Seatback Edge, NO.2 |
| 71610B | Spring Assy, Front Seat Cushion(FOR BENCH TYPE) |
| 71610S | Spring Assy, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71611 | Pad, Rear Seat Cushion |
| 71611A | Pad, Rear Seat Cushion, RH |
| 71612A | Pad, Rear Seat Cushion, LH |
| 71620S | Spring Assy, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71629 | Cover, Rear Seat Cushion Hinge |
| 71630B | Spring Assy, Front Seatback(FOR BENCH TYPE) |
| 71630S | Spring Assy, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71640S | Spring Assy, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71651 | Pad, Rear NO.1 Seatback |
| 71651B | Pad, Rear Seatback(FOR BENCH TYPE) |
| 71739 | Cushion, Seat Support |
| 71811D | Shield, Front Seat Cushion, RH |
| 71812D | Shield, Front Seat Cushion, LH |
| 71831D | Cover, Front Seat Hinge, RH |
| 71832D | Cover, Front Seat Hinge, LH |
| 71861 | Shield, Front Seat Cushion, Inner RH |
| 71862 | Shield, Front Seat Cushion, Inner LH |
| 71875A | Cover, Reclining Adjuster Inside, RH |
| 71875B | Cover, Reclining Adjuster Inside, RH |
| 71876 | Cover, Reclining Adjuster Inside, LH |
| 71876A | Cover, Reclining Adjuster Inside, LH |
| 71910A | Headrest Assy, Front Seat |
| 71931 | Support, Front Seat Headrest |
| 72011 | Adjuster Sub-assy, Front Seat, Outer RH |
| 72012 | Adjuster Sub-assy, Front Seat, Outer LH |
| 72021 | Adjuster Sub-assy, Front Seat, Inner RH |
| 72022 | Adjuster Sub-assy, Front Seat, Inner LH |
| 72110A | Track Assy, Front Seat, Outer RH |
| 72120 | Track Assy, Front Seat, Outer LH |
| 72125A | Cover, Seat Track, Upper Rear |
| 72129 | Protector, Seat Track Lower Rail, NO.1 |
| 72137 | Cover, Seat Track, Outer RH |
| 72137C | Cover, Seat Track Inner, RH |
| 72138 | Cover, Seat Track, Outer LH |
| 72138E | Cover, Seat Track, Inner LH |
| 72210E | Cable Assy, Seat Track Control(FOR WALK IN) |
| 72211 | Handle, Seat Track Adjusting |
| 72301 | Wire Sub-assy, Seat Track Equalizing |
| 72457 | Knob, Vertical Seat Adjuster |
| 72501D | Pipe Sub-assy, Reclining Connecting, RH |
| 72501E | Pipe Sub-assy, Reclining Connecting, LH |
| 72525A | Handle, Reclining Adjuster Release, RH |
| 72526A | Handle, Reclining Adjuster Release, LH |
| 72641 | Pin, Rear Seatback Lock |
| 72653A | Snap, Rear Seatback Lock Rod |
| 72750D | Adjuster Assy, Lumbar Support, RH |
| 72770 | Adjuster Assy, Lumbar Support, LH |
| 72791 | Lever, Lumbar Support |
| 72797 | Spacer, Lumbar Support |
| 87510K | Heater Assy, Front Seat Cushion, RH |
| 87510L | Heater Assy, Front Seat Cushion, LH |
| 87510M | Heater Assy, Front Seatback, RH |
| 87510N | Heater Assy, Front Seatback, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
