Toyota Hilux

2005-07 → 2012-04 · chassis KUN15,2# · catalogue 672570 · Europe

Supported model Data version 2012-04
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Speedometer Driven Gear (ATM)

2 part groups · 2 illustrations

Illustrations

Figure 354689E 354689E 2005-07 → — Figure 355079D 355079D 2006-10 → —

Part groups

PNCDescription
33403G Gear Sub-assy, Speedometer Driven (ATM)
33404K Clip (FOR ATM SPEEDOMETER SHAFT SLEEVE)
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
