Toyota Hilux (DCB/SCB/XTR)
2021-08 → 2023-01 · chassis GUN125,126,135 · catalogue 6725B0 · Europe
Supported model
Data version 2023-09
Side Member
40 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 53821B | Bracket, Front Fender, Rear RH |
| 53822B | Bracket, Front Fender, Rear LH |
| 58741C | Protector, Quarter Panel, RH |
| 58742C | Protector, Quarter Panel, LH |
| 61013C | Panel Sub-assy, Side, Inner RH |
| 61014C | Panel Sub-assy, Side, Inner LH |
| 61021C | Pillar Sub-assy, Front Body, RH |
| 61022C | Pillar Sub-assy, Front Body, LH |
| 61103G | Gusset Sub-assy, Front Body Pillar, Lower RH |
| 61104G | Gusset Sub-assy, Front Body Pillar, Lower LH |
| 61108A | Reinforce Sub-assy, Front Body Pillar, Lower RH |
| 61109A | Reinforce Sub-assy, Front Body Pillar, Lower LH |
| 61131 | Pillar, Front Body, Upper Outer RH |
| 61132 | Pillar, Front Body, Upper Outer LH |
| 61201 | Rail Sub-assy, Roof Side, RH |
| 61202 | Rail Sub-assy, Roof Side, LH |
| 61211 | Rail, Roof Side, Outer RH |
| 61212 | Rail, Roof Side, Outer LH |
| 61213B | Rail, Roof Side, Outer NO.2 RH |
| 61214B | Rail, Roof Side, Outer NO.2 LH |
| 61301 | Pillar Sub-assy, Center Body, RH |
| 61302 | Pillar Sub-assy, Center Body, LH |
| 61303 | Reinforce Sub-assy, Center Body Pillar, Upper RH |
| 61304 | Reinforce Sub-assy, Center Body Pillar, Upper LH |
| 61311B | Pillar, Center Body, Outer RH |
| 61312B | Pillar, Center Body, Outer LH |
| 61411A | Reinforcement, Rocker Panel, NO.1 RH |
| 61412A | Reinforcement, Rocker Panel, NO.1 LH |
| 61415B | Extension, Rocker, Outer RH |
| 61416B | Extension, Rocker, Outer LH |
| 61503B | Reinforcement Sub-assy, Quarter Lock Pillar, RH |
| 61504B | Reinforcement Sub-assy, Quarter Lock Pillar, LH |
| 61511 | Pillar, Quarter Lock, RH |
| 61512 | Pillar, Quarter Lock, LH |
| 61611 | Panel, Quarter, RH |
| 61612 | Panel, Quarter, LH |
| 61703G | Panel Sub-assy, Quarter, Inner RH |
| 61704H | Panel Sub-assy, Quarter, Inner LH |
| 67873H | Weatherstrip, Center Door, Upper NO.1 |
| 67874H | Weatherstrip, Center Door, Upper NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
