Toyota Hiace

1977-02 → 1982-11 · chassis RH11,2#,3#,42,LH11,20,30 · catalogue 691220 · Europe

Discontinued model Data version 1983-06

Steering Column & Shaft

36 part groups · 2 illustrations

PNC	Description
33621	Plate, Control Lever Caution
45201	Shaft Sub-assy, Steering Main
45201A	Bearing(FOR STEERING MAIN SHAFT)
45201B	Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
45205	Tube Sub-assy, Steering Column
45222	Cover, Steering Gear Dust
45230	Coupling Assy, Flexible
45240	Worm Assy, Steering
45240A	Bearing(FOR STEERING WORM)
45240B	Seal, Oil(FOR STEERING WORM)
45253	Cover, Steering Column Hole
45254	Shield, Steering Column Hole
45256	Protector, Column Tube Edge, NO.1
45269	Retainer, Main Shaft Bearing
45275	Bracket, Steering Column, Upper
45281	Housing, Steering Column
45292	Seal, Main Shaft Lower Dust
45296	Protector, Column Tube Edge, NO.2
45301	Housing Sub-assy, Steering Gear
45301A	Bush OR Bearing, Sector Shaft, NO.1
45301B	Seal, Oil(FOR SECTOR SHAFT)
45301D	Bolt, Stud(FOR STEERING GEAR HOUSING)
45301H	Bush OR Bearing, Sector Shaft, NO.2
45310	Housing Assy, Steering Gear
45312	Bracket, Steering Gear Housing
45321	Cover, Gear Housing End
45323	Shim, Gear Housing End Cover
45331	Cover, Sector Shaft End
45332	Gasket, Sector Shaft End Cover
45351	Shaft, Steering Sector
45351A	Nut, Hexagon(FOR SECTOR SHAFT TO PITMAN ARM SETTING)
45352	Washer, Sector Shaft Thrust
45357	Screw, Sector Shaft Adjusting
45372	Plug, Steering Gear Housing Oil
45401	Arm Sub-assy, Pitman
45895	Plate, Steering Lock Caution

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
