Toyota DYNA100

1987-08 → 1995-05 · chassis YH81,LH80 · catalogue 691250 · Europe

Discontinued model Data version 1995-10
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Rear Body Side Panel

26 part groups · 2 illustrations

Illustrations

Figure MBP069B MBP069B 1987-08 → — Figure MBV871B MBV871B 1987-08 → —

Part groups

PNCDescription
65313 Panel, Floor Front Corner, RH
65314 Panel, Floor Front Corner, LH
65315 Panel, Floor Rear Corner, RH
65316 Panel, Floor Rear Corner, LH
65500 Panel Assy, Rear Body Side, RH
65508C Support Sub-assy, Side Gate, LH
65519 Bracket, Top Rail
65519A Bracket, Top Rail
65577 Retainer, Tail Gate Latch Female
65577A Retainer, Tail Gate Female
65600 Panel Assy, Rear Body Side, LH
65679E Seal, Side Gate
66013A Support Sub-assy, Side Gate, RH
66021A Handle Sub-assy, Side Gate Support Corner, RH
66022A Handle Sub-assy, Side Gate Support Corner, LH
66110C Hinge Assy, Side Gate, NO.1 RH
66115C Retainer, Gate Hinge
66153A Latch, Tail Gate Female, RH
66154A Latch, Tail Gate Female, LH
66187 Handle, Side Gate Latch, Center NO.2
66311E Hook, Rope
66332 Cushion, Rubber
66770 Support Sub-assy, Side Gate, RH
66780 Support Sub-assy, Side Gate, LH
66783 Bracket, Side Gate Support, RH
66784 Bracket, Side Gate Support, LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
