Toyota Hiace Van,Commuter
1989-08 → 2006-02 · chassis LH1##,RZH10#,11#,125,135,15# · catalogue 711340 · Europe
Discontinued model
Data version 2006-10
Roof Headlining & Silencer Pad
62 part groups · 10 illustrations
Part groups
| PNC | Description |
|---|---|
| 62213A | Pad, Front Pillar Garnish |
| 62410A | Garnish Assy, Center Pillar, RH |
| 62410B | Clip |
| 62417E | Pad, Center Pillar Garnish, NO.1 |
| 62418D | Pad, Center Pillar Garnish, NO.2 |
| 62420A | Garnish Assy, Center Piller, LH |
| 62430C | Garnish Assy, Roof Side Rail, RH |
| 62440A | Garnish Assy, Roof Side Rail, Front LH |
| 62440C | Garnish Assy, Roof Side Rail, LH |
| 62450 | Garnish Assy, Roof Side Rail, Rear RH |
| 62460 | Garnish Assy, Roof Side Rail, Rear LH |
| 62465A | Pad, Quarter Lock Pillar, RH |
| 62466A | Pad, Quarter Lock Pillar, LH |
| 63310 | Headlining Assy, Roof |
| 63310D | Clip, Roof Headlining |
| 63310H | Clip(FOR ROOF HEADLINING) |
| 63311A | Headlining, Roof NO.1 |
| 63312A | Headlining, Roof, NO.2 |
| 63313A | Headlining, Roof, NO.3 |
| 63314A | Headlining, Roof, NO.4 |
| 63315A | Headlining, Roof, NO.5 |
| 63318C | Moulding, Sun Roof Opening Trim |
| 63319C | Joint, Sun Roof Opening Trim |
| 63320F | Headlining Assy, Sun Roof |
| 63325B | Plate, Roof Headlining Set, RH |
| 63326B | Plate, Roof Headlining Set, LH |
| 63330A | Headlining Assy, Roof, Rear |
| 63341 | Pad, Roof Silencer, NO.1 |
| 63342 | Pad, Roof Silencer, NO.2 |
| 63343 | Pad, Roof Silencer, NO.3 |
| 63344 | Pad, Roof Silencer, NO.4 |
| 63345 | Pad, Roof Silencer, NO.5 |
| 63346 | Pad, Roof Silencer, NO.6 |
| 63351B | Pad, Roof Headlining |
| 63361 | Support, Roof Headlining, NO.1 |
| 63362 | Support, Roof Headlining, NO.2 |
| 63363 | Support, Roof Headlining, NO.3 |
| 63364 | Support, Roof Headlining, NO.4 |
| 63365 | Support, Roof Headlining, NO.5 |
| 63365A | Plate, Roof Headlining Set |
| 63366 | Support, Roof Headlining, NO.6 |
| 63367 | Support, Roof Headlining, NO.7 |
| 63368 | Support, Roof Headlining, NO.8 |
| 63369 | Support, Roof Headlining, NO.9 |
| 63369A | Support, Roof Headlining, NO.10 |
| 63369D | Support, Roof Headlining, NO.7 |
| 63369E | Support, Roof Headlining, NO.11 |
| 63371D | Retainer, Roof Headlining Support |
| 63372C | Hook, Roof Headlining Support |
| 63381 | Retainer, Headlining, Front |
| 63383D | Retainer, Roof Headlining, Rear |
| 63384B | Bracket, Roof Headlining Trim Retainer |
| 63391 | Trim, Roof Headlining, Front |
| 63393E | Trim, Roof Headlining |
| 63395 | Clip, Roof Headlining Trim |
| 63643 | Rail, Sunshade, NO.1 Rear RH |
| 63644A | Rail, Sunshade, NO.1 Rear LH |
| 63681A | Rail, Sunshade, NO.1 Front |
| 63687 | Bracket, Sunshade Rail |
| 63711 | Bracket, Roof Lining, Front RH |
| 63721A | Bracket, Roof Lining, Front LH |
| 74613A | Reinforcement, Front Assist Grip |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
